85 Air Boom 485

Нет текстового описания

№ на схеме	Серийный номер	Кол-во	Название	Описание
-	-	1	Hydraulic Hoses, Dual Bin And Tri Bin Distribution (2 of 2)	-
-	-	1	Oil Cooler, Dry Box Spreader	-
-	-	1	Mud Flaps, Air Boom Spreader	-
-	-	1	Motor and Valve, Conveyor	-
-	-	1	Material Deflector, Dry Box Spreader, LH Illustrated	-
-	-	1	Material Deflector Kit, Dry Box Spreader, Attachment	-
-	-	1	Hydraulic Reservoir, Dry Box Spreader	-
-	-	1	Hydraulic Motor, Granular Bin	-
-	-	1	Hydraulic Hoses, Pump	-
-	-	1	Pilot Hydraulic Control Valve, Conveyor	-
-	-	1	Hydraulic Hoses, Dual Bin And Tri Bin Distribution (1 of 2)	-
-	-	1	Hydraulic Hoses, Dry Spreader Granular Bin	-
-	-	1	Hydraulic Hoses, Dry Box Spreader (2 of 2)	-
-	-	1	Hydraulic Hoses, Dry Box Spreader (1 of 2)	-
-	-	1	Hydraulic Filter, Dry Box Spreader	-
-	-	1	Hydraulic Cylinder, Dry Box Spreader	-
-	-	1	Grease Hoses, Dry Box Spreader, RH Illustrated	-
-	-	1	SMV Emblem and Speed Decal	-
-	-	1	Wiring Harness, Jumper, Air Boom	-
-	-	1	Wiring Harness, Air Boom System (3/3)	-
-	-	1	Wiring Harness, Air Boom System (2/3)	-
-	-	1	Wiring Harness, Air Boom System (1/3)	-
-	-	1	Venturi, Dry Box Spreader Distribution Manifold	-
-	-	1	Vehicle Controller, Dry Box Spreader	-
-	-	1	Tank, Dry Spreader Granular Bin	-
-	-	1	Spanish Decals	-
-	-	1	Grease Hoses, Dry Box Spreader, Front	-
-	-	1	Sensor, Dry Box Spreader	-
-	-	1	Secondary Hydraulic Pump, 38 cc	-
-	-	1	Rear Light / Bracket, LH Illustrated	-
-	-	1	Rear Beacon Light Harness	-
-	-	1	Primary Hydraulic Pump, 90 cc	-
-	-	1	Platform / Handrails, Dry Box Spreader	-
-	-	1	Pilot Hydraulic Valve, Granular Bin Control	-
-	-	1	Bracket / Bearing, Dual Conveyor, Dry Box Spreader, RH Illustrated	-
-	-	1	Divider, Material Collection	-
-	-	1	Decals	-
-	-	1	Conveyor, Dry Box Spreader	-
-	-	1	Conveyor Gearbox	-
-	-	1	Chassis Wiring Harness, Dry Box Spreader (3/3)	-
-	-	1	Chassis Wiring Harness, Dry Box Spreader (2/3)	-
-	-	1	Chassis Wiring Harness, Dry Box Spreader (1/3)	-
-	-	1	Bracket / Support, Blower Fan	-
-	-	1	Dry Box Lighting Harness	-
-	-	1	Boom Tilt Link, RH Illustrated	-
-	-	1	Boom Swing Arm, LH Illustrated	-
-	-	1	Boom Supports, Dry Box Spreader	-
-	-	1	Boom Sequence Control Valve	-
-	-	1	Boom Motion Control Valve	-
-	-	1	Blower Fan, W/ Elbow	-
-	-	1	Beacon Light, Air Boom Spreader	-
-	-	1	Arm / Linkage, Boom Tip Fold, RH Illustrated	-
-	-	1	Dry Box Spreader Mountings (1 of 2)	-
-	-	1	Dry Box Spreader Mountings (2 of 2)	-
-	-	1	Dry Box Spreader, Dual Bin (1 of 2)	-
-	-	1	Dry Box Spreader, Dual Bin (2 of 2)	-
-	-	1	Dry Spreader Granular Bin Harness Kit, Attachment	-
-	-	1	Dry Spreader Granular Bin W/ Harness Kit, Attachment	-
-	-	1	Dry Spreader Granular Bin, Attachment	-
-	-	1	Dual Bin Tank	-
-	-	1	English Decals	-
-	-	1	Fender, Air Boom Spreader, RH Illustrated	-
-	-	1	Flow Control Hydraulic Valve, Fan Servo Throttle	-
-	-	1	French Decals	-
-	-	1	Gear / Bearing / Splined Coupling / Hydraulic Motor, Dry Spreader Granular Bin	-
-	-	1	Grate (1 of 2)	-
-	-	1	Grate (2 of 2)	-
