Открытый узел

50 PowrQuad™ Transmission

Серийный номер

Бренд

John Deere

Читать описание

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
-	-	1	PTO Housing (010000 - )	-
-	-	1	Shifter Components, Mechanical Shifters	-
-	-	1	Shield, PTO Guard	-
-	-	1	Shaft, PTO Input	-
-	-	1	Rear PTO Solenoid Control Valve (010000 - )	-
-	-	1	Rear PTO Output Shaft	-
-	-	1	Rear PTO Housing (010000 - )	-
-	-	1	Rear PTO Housing	-
-	-	1	Range Box Output Shaft, 30 km/h (18.5 mph)	-
-	-	1	PTO Output Drive Shaft	-
-	-	1	Shifter Cover, 30 km/h (18.5 mph)	-
-	-	1	Power Take-Off Guard	-
-	-	1	Plug, Rear PTO Housing (010000 - )	-
-	-	1	Planet Pinion Carrier	-
-	-	1	Parking Lock, W/ RH Reverser, PowrQuad™	-
-	-	1	Parking Lock, PowrQuad™, 30 km/h (18.5 mph) / 40 km/h (25 mph)	-
-	-	1	Parking Lock, 30 km/h (18.5 mph), High Crop	-
-	-	1	Parking Lock, 30 km/h (18.5 mph) / 40 km/h (25 mph)	-
-	-	1	Output Shaft, PTO, 540/1000	-
-	-	1	Output Shaft, PowrQuad™, W/ Electrical Reverser Control (010000 - )	-
-	-	1	Transmission Cover W/O MFWD	-
-	-	1	Universal Drive Shaft, W/ Torsion Damper	-
-	-	1	Universal Drive Shaft	-
-	-	1	Transmission, Creeper Module	-
-	-	1	Transmission Output Shaft W/O Creeper, PowrQuad™	-
-	-	1	Transmission Oil Pump	-
-	-	1	Transmission Oil Filter	-
-	-	1	Transmission Front Cover, PowrQuad™, W/ Mechanical Reverser Control (010000 - )	-
-	-	1	Transmission Front Cover, PowrQuad™ Transmission, 17 Bar (010000 - )	-
-	-	1	Transmission Front Cover	-
-	-	1	Output Shaft, PowrQuad™, W/ Creeper (010000 - )	-
-	-	1	Transmission Case, Creeper (025000 - )	-
-	-	1	Traction Clutch Assembly, 4 Disks	-
-	-	1	Traction Clutch Assembly	-
-	-	1	Solenoid Valve, MFWD ( - 009999)	-
-	-	1	Solenoid Control Valve, Rear PTO	-
-	-	1	Sight Gauge (010000 - )	-
-	-	1	Shifter Rod, W/ Mechanical Reverser Control, W/O Creeper	-
-	-	1	Shifter Rod, PowrQuad™, W/ Mechanical Reverser Control, W/ Creeper	-
-	-	1	Differential Housing, AutoQuad™ / CommandQuad™ (010000 - )	-
-	-	1	Hitch Draft Sensor	-
-	-	1	Gearshift Lever, W/O Shifter Lever Unit (010000 - )	-
-	-	1	Gauge, Oil Level	-
-	-	1	Front Valve Housing and Valve, PowrQuad™, W/ Mechanical Reverser Control (010000 - )	-
-	-	1	Front Support, Rear PTO	-
-	-	1	Forward Clutch, PowrQuad™ (010000 - )	-
-	-	1	Filler Neck, Transmission Oil	-
-	-	1	Filler Neck, Transmission Oil	-
-	-	1	Differential Lock, Oil Lines, W/O Creeper	-
-	-	1	Housing Planetary Brake	-
-	-	1	Differential Housing	-
-	-	1	Differential Assembly	-
-	-	1	Countershaft, PTO, 1000 / 540	-
-	-	1	Clutch, Rear PTO	-
-	-	1	Clutch, PowrQuad™ B1, B2 and B3	-
-	-	1	Breather, Differential Housing (010000 - )	-
-	-	1	Breather, Differential Housing	-
-	-	1	Brake Disk, AutoQuad™ or CommandQuad™ (010000 - )	-
-	-	1	Input Shaft, Range Transmission, 30 km/h (19 mph)	-
-	-	1	Output Shaft and Mounting Parts, PowrQuad™, W/ Creeper	-
-	-	1	Oil Filter, PowrQuad™ Transmission (010000 - )	-
-	-	1	Multi Disk Clutch, MFWD	-
-	-	1	Mounting Parts, PowrQuad™, W/ Mechanical Reverser Control	-
-	-	1	Mounting Parts, MFWD Clutch Module, W/ Shield Plate	-
-	-	1	MFWD Housing, 40 km/h (25 mph)	-
-	-	1	MFWD Control Valve (010000 - )	-
-	-	1	Load Control Shaft, Draft Sensor (010000 - )	-
-	-	1	Input Shaft, Transmission	-
-	-	1	5 Disk Reverse Brake, PowerQuad™	-
-	-	1	Housing, Transmission Oil Filter	-
-	-	1	Housing, Range Box, W/ Wheel Speed Sensor	-
-	-	1	Housing, Planetary Brake Assembly, W/ Oil Evacuation Manifold, PowrQuad™ or CommandQuad™ (010000 - )	-
-	-	1	Housing, Front Cover and Valves	-
-	-	1	Housing, 5 Disk Reverse Brake, PowerQuad™	-
-	-	1	Housing, 4-Speed Shifting W/ Mechanical Reverser Control (010000 - )	-
-	-	1	Housing, 4-Speed Shifting W/ Mechanical Reverser Control	-
-	-	1	Housing, 4 - Speed Shifting W/ Mechanical Reverser Control (010000 - )	-

50 PowrQuad™ Transmission

Нет текстового описания
