Открытый узел

Hose kit 3400000551-

Серийный номер

Бренд

Komatsu / Valmet

Читать описание

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	5093001	1	Hydraulic hose	3/4" L=1300 R-45° ORFS;;
2	5093002	1	Hydraulic hose	CM2T-12/1240/4224-16-12/4100-22-12;;
3	5093003	1	Hydraulic hose	3/4" L=1300 R-45° ORFS;;
4	5093004	1	Hydraulic hose	3/4" L=1235 R-45° ORFS;;
10	5093005	1	Hydraulic hose	CM2T-12/475/4224-12-12/504922Y/120°;;
11	5093203	1	Hydraulic hose	EFG5K-12/640/4244-12-12/504922Y/90°;;
12	5093007	1	Hydraulic hose	G1-06/900/4224-06-06 L/4294-06-06;;
13	5093008	1	Hydraulic hose	CM2T-04/1190/4294-04-04/4224-04-04 L;;
14	5093009	1	Hydraulic hose	CM2T-04/565/4224-06-04 L/4244-06-04;;
15	5093010	1	Hydraulic hose	G1-04/280/4914-04-04/4914-04-04/90°;;
16	5093011	1	Hydraulic hose	CM2T-04/800/4244-06-04/4914-04-04/20°;;
17	5093012	1	Hydraulic hose	CM2T-04/500/4244-04-04/4224-04-04 L;;
18	5093013	1	Hydraulic hose	G1-04/190/4914-04-04/4914-04-04/90°;;
19	5093014	1	Hydraulic hose	E-03/240/P71-03-09ISO/4224-04-03;;
20	5093015	1	Hydraulic hose	E-03/130/4914-02-03/4224-04-03;;
21	5093016	1	Hydraulic hose	E-03/230/4224-04-03/4914-02-03;;
22	5093017	1	Hose	E-03/750/P8-02-03/4914-02-03;;
30	5093019	2	Hydraulic hose	CM2T-06/500/P70-06-11ISO/P70-06-11ISO;;
31	5093020	1	Hydraulic hose	CM2T-06/420/4224-06-06 L/4294-06-06;;
32	5093021	1	Hydraulic hose	CM2T-06/245/06G-06FForx90S/4224-06-06 L;;
33	5093022	1	Hydraulic hose	CM2T-06/245/4010-06-06/06G-06FForx90S;;
40	5093023	2	Hydraulic hose	M5K-08/625/4224-08-08L/4294-10-08/180°;;
41	5093024	2	Hydraulic hose	M5K-08/730/4224-10-08/4294-10-08/180°;;
42	5093025	2	Hydraulic hose	CM2T-06/570/4244-06-06/4224-06-06 L/180°;;
50	5093026	1	Hydraulic hose	CM2T-06/410/P71-06-11/4224-06-06 L;;
51	5093027	1	Hydraulic hose	CM2T-06/710/4224-06-06 L/4294-06-06;;
52	5093028	1	Hydraulic hose	CM2T-04/360/4294-06-04/4224-06-04 L;;
53	5093029	1	Hydraulic hose	CM2T-04/280/4224-06-04 L/4244-06-04;;
60	5093202	1	Hydraulic hose	CM2T-04/855/4224-06-04L/4010-04-04;;
61	5093031	1	Hydraulic hose	CM2T-04/760/4224-06-04 L/4294-06-04;;
62	5093032	1	Hydraulic hose	CM2T-04/190/4244-06-04/4294-06-04/10°;;
70	5093033	1	Hydraulic hose	CM2T-04/1565/4224-06-04 L/4294-06-04;;
71	5093201	1	Hydraulic hose	CM2T-04/1775/4224-06-04L/4294-06-04;;
72	5093034	1	Hydraulic hose	CM2T-04/780/4224-06-04 L/4224-06-04 L;;
73	5093035	1	Hydraulic hose	CM2T-04/500/4224-06-04 L/4294-06-04;;
74	5093036	1	Hydraulic hose	CM2T-04/470/4244-06-04/4224-06-04 L;;
75	5093037	1	Hydraulic hose	CM2T-04/745/4244-06-04/4224-06-04 L;;
80	5093038	1	Hydraulic hose	CM2T-04/683/4294-04-04/4224-04-04 L;;
81	5093039	1	Hydraulic hose	CM2T-04/645/4294-04-04/4224-04-04 L;;
90	5093040	2	Hydraulic hose	2807-03BK/210/6103-04-03/6192-10-03;;
91	5093040	1	Hydraulic hose	2807-03BK/210/6103-04-03/6192-10-03;;
92	5093041	1	Hose	2807-03 BK/550/6103-04-03/P71-02-09ISO;;
100	5093042	1	Hydraulic hose	CM2T-04/1935/4224-06-04 L/4244-06-04;;
101	5093043	1	Hydraulic hose	CM2T-04/1725/4224-06-04 L/4244-06-04;;
102	5093044	1	Hydraulic hose	CM2T-04/515/4224-06-04 L/4294-04-04;;
103	5237913	1	Hydraulic hose	CM2T-06/1015/4294-06-06/4224-06-06 L;;
110	5093497	1	Hydraulic hose	-
112	5093048	2	Hydraulic hose	G1-06/385/4010-06-06/4710-12-06;;
120	5093049	1	Hose	2807-03BK/440/6103-04-03/6192-10-03;;
121	5093050	1	Hose	2807-03 BK/510/6117-04-03/6192-10-03/0°;;
122	5093204	1	Hose	2807-03BK/1150/6103-04-03/6193-10-03;;
123	5093204	1	Hose	2807-03BK/1150/6103-04-03/6193-10-03;;
124	5093052	1	Hydraulic hose	CM2T-04/1480/4224-04-04 L/4224-04-04 L;;
125	5093053	1	Hydraulic hose	CM2T-04/1440/4224-04-04L/4294-04-04;;
126	5093054	1	Hydraulic hose	E-03/460/4914-04-03/4914-02-03/0°;;
127	5093055	1	Hydraulic hose	CM2T-04/365/4294-04-04/4224-04-04 L;;
128	5093089	1	Hydraulic hose	2807-03 BK/370/6103-04-03/6192-10-03;;
129	5093090	1	Hydraulic hose	2807-03 BK/440/6117-04-03/6192-10-03/0°;;
140	5093496	1	Hydraulic hose	CM2T-04/2000/4224-06-04/4914-02-04;;
141	5093057	1	Hydraulic hose	3/16" L=300 R-banjo BSP;;
142	5093018	1	Hydraulic hose	3/16" L=400 R-R BSP;;
150	5237912	1	Hydraulic hose	CM2T-06/F330/4224-06-06L/4294-06-06;;
151	5237906	1	Hydraulic hose	CM2T-06/300/4224-06-06L/4294-06-06;;
152	5237908	2	Hydraulic hose	CM2T-06/F315/4244-06-06/4224-06-06L;;
153	5237910	2	Hydraulic hose	CM2T-06/F520/4914-06-06/4224-06-06L;;
154	5237911	1	Hydraulic hose	CM2T-06/1290/4244-06-06L/4224-06-06L;;
155	5229651	1	Hydraulic hose	CM2T-06/300/4244-06-06/4224-06-06 L;;
156	5229650	1	Hydraulic hose	CM2T-06/1200/4100-12-06/4224-08-06;;
-	5241652	1	Hose kit	340;;

Hose kit 3400000551-

Нет текстового описания
