Открытый узел

70 Hydraulic System Combine W660 - MY12

Серийный номер

Бренд

John Deere

Читать описание

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
-	-	1	Oil Lines And Connecting Parts (Hydraulic Pump) - IT4	-
-	-	1	Hydraulic Return Lines, With Chaff Spreader - IT4	-
-	-	1	Hydraulic/Hydrostatic Oil Reservoir and Mountings	-
-	-	1	Hydraulic/Hydrostatic Oil Reservoir And Mountings - IT4	-
-	-	1	Main Hydraulic Filter Assembly	-
-	-	1	Main Hydraulic Pump	-
-	-	1	Main Valve Block	-
-	-	1	Main Valve Block	-
-	-	1	Multi-Coupler - Exploded View	-
-	-	1	Oil Cooler And A/C Condenser	-
-	-	1	Hydraulic Return Lines, With Chaff Spreader	-
-	-	1	PBS Transmission Hoses	-
-	-	1	Reel and Belt Pickup Charge Pump Mounting and Sheave	-
-	-	1	Reel Lift Lines And Hoses	-
-	-	1	Reverser Valve, Reel Drive and Hydraulic Lines	-
-	-	1	Seal Kit For Flow Control Valve	-
-	-	1	Tilt Cylinder - Headertrak	-
-	-	1	Unloading Auger Swing Cylinder And Mounting	-
-	-	1	Unloading Auger Swing Cylinder Lines And Hoses	-
-	-	1	Wet Clutch, Oil Cooler Lines and Hoses	-
-	-	1	Engine - Gear Case Pressure Regulator	-
-	-	1	Adjusting Screw Kit For Flow Control Valve	-
-	-	1	Chaff Spreader Motor	-
-	-	1	Chaff Spreader Motor And Connecting Lines	-
-	-	1	Chaff Spreader Operating Element	-
-	-	1	Chaff Spreader Pump, Valve And Hoses	-
-	-	1	Combination Valve	-
-	-	1	Components Of Solenoid Valve Block	-
-	-	1	Connecting Lines For Chaff Spreader Motor	-
-	-	1	Cylinder Speed Hydraulic Lines And Hoses	-
-	-	1	Accumulator (AHC)	-
-	-	1	Engine Gear Case Oil Filter Assembly	-
-	-	1	Flow Control Valve Parts	-
-	-	1	Grain Tank Unloading Drive Cylinder With Mounting And Hose	-
-	-	1	Header Lift Hydraulic Cylinder	-
-	-	1	Header Lift Hydraulic Lines And Hoses	-
-	-	1	Headertrak Hydraulic Hoses, L.H. Side (Optional)	-
-	-	1	Hydraulic Lines Without Chaff Spreader	-
-	-	1	Hydraulic Pressure Lines And Hoses	-
-	-	1	Hydraulic Pressure Lines And Hoses- IT4	-

70 Hydraulic System Combine W660 - MY12

Нет текстового описания
