AUXILIARY WINCH HYDRAULIC DRIVE MOTOR [02J18]

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	T38839	2	PLATE	-
2	T38837	1	STEERING GEAR	(8 TEETH)
3	T38836	1	STEERING GEAR	(14 TEETH)
4	T38843	1	PLATE	-
5	T38845	1	STRIP	-
6	T38840	2	SEPARATOR	CENTER
7	T38838	4	SEPARATOR	END
8	T38849	4	WASHER	-
9	U15415	4	O-Ring	(SUB FOR T38850)
10	T38844	2	WASHER	-
11	U44861	1	O-RING	-
11	-	1	Part 12	( T41418 USE IF AVAILABLE)
12	400R	2	Ball	6.35 MM (1/4") (SUB FOR U44850)
13	AT41083	1	FLANGE	-
13	AT37712	1	FLANGE	(SUB AT41083 AND T41418)
14	19H2898	8	Cap Screw	1/2" X 1-1/4" HS, SAE 8, (SUB FOR T38846)
15	U44865	8	WASHER	-
16	U44854	2	DOWEL PIN	-
17	D2361R	2	Ball	(SUB FOR T38851)
18	T38842	2	RETAINER	-
19	12H294	2	Lock Washer	5/8"
20	19H1708	2	CAP SCREW	5/8" X 1-3/4"
21	T38841	2	PLATE	-
22	AT37711	1	HOUSING	-
23	R26448	1	O-Ring	(SUB FOR T38847)
24	T38848	1	PLUG	-
25	AT36613	1	MOTOR	(A)
90	AT40858	1	WINCH	(UNIT MUST BE EQUIPPED WITH 100 CM3 (6.00 CU. IN.) HYDRAULIC PUMP) (NO LONGER AVAILABLE) (CONTAINS ALL PARTS IDENTIFIED BY (A) ON THIS AND PAGES LISTED IN FOOTNOTE ON PAGE TITLED LOG ARCH AND FAIRLEAD (SERIAL NO. -218

AUXILIARY WINCH HYDRAULIC DRIVE MOTOR [02J18]
