DECALS AND LABELS [03B24]

Нет текстового описания

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	T59907	2	LABEL	(A) SERIES DESIGNATION, (SUB FOR T38054)
2	T29432	1	LABEL	TRANSMISSION, LOW RANGE
3	T29431	1	LABEL	TRANSMISSION, HIGH RANGE
4	T45810	1	LABEL	SERVICE BRAKE RELEASE
5	T27580	1	LABEL	(A) AIR CLEANER
6	T41929	1	LABEL	IMPORTANT
7	T50844	2	SAFETY SIGN	(A) SAFETY
8	T58390	1	LABEL	CHAIN ADJUSTMENT
9	-	1	Part 9	(A) BATTERY CONNECTION AND CAUTION ( T23616 NO LONGER AVAILABLE)
11	T72047	1	LABEL	(A) HYDRAULIC OIL LEVEL, (SUB FOR T41927)
12	JD5625	2	LABEL	(A) LEAPING DEER, (SUB FOR JD5429 AND JD5607, THIS APPLICATION)
13	T38052	1	LABEL	(A) GEAR SHIFT QUADRANT
14	T53927	1	LABEL	WINCH VALVE
15	T30284	2	SAFETY SIGN	(A) SAFETY
16	T152453	1	SAFETY SIGN	(A) (SUB FOR T64289) SAFETY
17	T65414	1	LABEL	(A) PERIODIC SERVICE, (SUB FOR T41926)
18	T44607	1	INSTRUCTION PLATE	OPERATING INSTRUCTIONS
19	AT69028	1	DECALS	(SUB FOR AT64951)
20	T58240	1	LABEL	HEATER CONTROL
21	T62460	1	LABEL	WINDOW
22	T42170	1	Label	STARTING AID
23	T53707	1	LABEL	STARTING AID
24	R81424	1	Safety Sign	SEAT BELT, (SUB FOR R42732)
25	T35672	1	LABEL	START AND STOP PROCEDURE
26	T29392	1	LABEL	HORN
27	T58268	1	LABEL	(A) OSHA ROPS
28	T56890	1	SAFETY SIGN	SAFETY, (SUB FOR T44093)
29	T43705	1	SAFETY SIGN	SEAT BELT CAUTION
30	T146431	5	SAFETY SIGN	ACCUMULATOR (INCLUDES FOUR FOR SECONDARY STEERING)
31	T152457	2	Label	(SUB FOR T81939) BLADE CLEARANCE
32	T81506	1	SAFETY SIGN	SAFETY
33	T146102	1	Label	START SAFETY, (SUB FOR T75512, T146102 AND T146102 OR T146102)
90	-	1	Part 35	REFINISHING DECAL ( AT58650 NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS) (INCLUDES PARTS MARKED (A) ON THIS PAGE AND PAGES LISTED IN FOOTNOTE)
10A	T41928	1	LABEL	LEVER
10B	T53999	1	LABEL	LEVER, (SUB FOR T49229)
