STEERING VALVE ASSEMBLY (SERIAL NO. 50000-83999) [01H15]

Серийный номер

Бренд

John Deere

Читать описание

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	R34733	2	WASHER	-
2	R41724	4	PLUG	(SUB FOR R34130)
3	R32588	6	Back-Up Ring	-
4	R459R	6	O-Ring	-
5	R26565	4	COMPRESSION SPRING	-
6	400R	4	Ball	-
7	R28124	4	VALVE	-
8	AR30589	2	SHAFT	UPPER, WITH GUIDE
8	AR30590	2	SHAFT	LOWER, WITH GUIDE
9	R34131	2	Plug	-
10	AR26725	1	ELBOW FITTING	-
11	R26448	1	O-Ring	-
12	R27094	2	Drain Plug	-
13	R26286	2	O-Ring	-
14	R28505	1	SOLID SHIM	.762 MM (.030")
14	R28786	1	SOLID SHIM	.254 MM (.010")
14	R28785	1	SOLID SHIM	.127 MM (.005")
14	R32637	1	SOLID SHIM	.077 MM (.003")
15	AR26767	1	TEE FITTING	(TRACTORS EQUIPPED WITH SELECTIVE CONTROL)
16	AR26773	1	ELBOW FITTING	(TRACTORS LESS SELECTIVE CONTROL)
17	R26286	1	O-Ring	-
18	AR43559	1	HOUSING	GUIDES AND METERING SHAFTS, (MARKED R34119) (SUB FOR AR34006)
19	AR26746	1	Elbow Fitting	(NOT AS ILLUSTRATED)
20	R26287	1	O-Ring	-
21	19H1805	4	CAP SCREW	1/2" X 2-1/4"
21	12H301	4	Lock Washer	1/2"
22	R26425	2	SNAP RING	-
23	R40595	2	BEARING RACE	(SUB FOR R34126)
24	R26552	13	Ball	-
25	R40757	1	BUSHING	(SUB FOR R31197)
26	R34128	4	WASHER	-
27	R20228	1	NUT	(SUB FOR C1200R)
28	R39112	1	Fitting	(SUB FOR R28095)
29	R26375	1	O-Ring	-
30	R31278	1	SPRING	-
31	R42849	1	Ball	(SUB FOR 405R)
32	R30323	1	BACK-UP RING	-
33	T12860	1	O-RING	-
34	B2762R	1	O-Ring	-
35	R26546	1	BACK-UP RING	-
36	R34123	1	VALVE SEAT	-
37	R42661	1	SEAT	(SUB FOR R34124)
38	R26151	1	SPRING	-
39	R34122	1	STOP	-
40	R34132	1	VALVE SEAT	(SUB AR44883 COVER WITH SEAT)
41	R34129	1	Back-Up Ring	-
42	A4365R	1	O-Ring	-
43	400R	1	Ball	-
44	R26373	1	Spring	-
45	R34336	1	GUIDE	-
46	R31631	1	DRAIN PLUG	-
47	R26287	1	O-Ring	-
48	19H2552	6	CAP SCREW	3/8" X 1-1/8"
48	12H304	6	Lock Washer	3/8"
49	19H1721	2	CAP SCREW	1/2" X 1-1/2"
49	12H301	2	Lock Washer	1/2"
50	R26553	1	COVER	-
51	14H649	4	Nut	1/4"
52	AR26402	1	LEVER	UPPER
53	R31217	2	SCREW	(SUB FOR R26762, THIS APPLICATION)
54	AR26448	1	LEVER	LOWER
55	R26554	2	SET SCREW	-
..	AR39585	1	KIT	STEERING PISTON, CYLINDER AND VALVE ASSEMBLY OVERHAUL (CONTAINS (ALL THE NECESSARY O-RINGS, PACKING, BACKUP RINGS, PAPER WASHERS AND OIL SEAL TO COMPLETELY OVERHAUL THE STEERING VALVE ASSEMBLY)
