STEERING PISTON AND CYLINDER ASSEMBLY [01H13]

Серийный номер

Бренд

John Deere

Читать описание

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	R34324	1	DECAL	-
2	B3690R	1	O-Ring	-
3	14H904	1	Nut	3/4"
4	R71650	1	LOCK WASHER	(SUB FOR T17148, THIS APPLICATION)
5	AR26625	1	STEERING WHEEL	-
6	B169R	1	SNAP RING	-
7	24H1659	1	Washer	29/32" X 1-5/8" X 0.120"
8	R32730	1	SEAL	(SUB FOR AR34172, THIS APPLICATION)
9	R26933	1	SNAP RING	-
10	R27320	1	BUSHING	-
11	21H979	1	SCREW	0.190" X 5/16"
12	R27299	1	SCREW	-
13	R27453	1	Nut	-
14	-	1	Part 14	-
15	400R	1	Ball	-
16	AR32699	1	CYLINDER	BUSHING, THRUST BEARING, AND DOWEL PINS, (MARKED R34117)
17	R27087	1	WASHER	-
18	R32186	2	DOWEL PIN	-
19	R26441	2	BACK-UP RING	-
20	A3606R	2	O-RING	-
21	R26448	1	O-Ring	-
22	AR26725	1	ELBOW FITTING	-
23	-	1	Part 23	(SUB FOR R26760) (ORDER AR67783 PACKING KIT)
24	19H2461	4	CAP SCREW	3/8" X 1-1/4"
24	12H304	4	Lock Washer	3/8"
25	R26287	1	O-Ring	-
26	R31631	1	DRAIN PLUG	-
27	AR30297	1	PISTON	WITH ROD AND SYNCHRONIZING VALVE SHIFT
28	-	1	Part 29	(SUB AR30298 PISTON, WITH ROD AND SNAP RING) ( R27510 NO LONGER AVAILABLE)
29	R31202	5	VALVE	-
30	R26287	2	O-Ring	-
31	R31201	2	SHAFT	-
32	H871R	2	Ball	-
33	A4816R	1	SPRING	-
34	-	1	Part 35	(SUB AR30298 PISTON, WITH ROD AND SNAP RING) ( R34554 NO LONGER AVAILABLE)
35	F534R	1	Snap Ring	-
36	R26754	2	BACK-UP RING	(SUB R40567 THIS APPLICATION)
37	R26543	1	O-Ring	(SUB R40567 THIS APPLICATION)
37	R40567	1	WASHER	-
38	11H206	1	Cotter Pin	3/32" X 3/4"
39	R34125	1	SHAFT	-
40	34H282	1	Spring Pin	3/16" X 1"
41	R27319	1	SPLINED COUPLING	-
42	R28137	1	STEERING SHAFT	-
43	-	1	Part 45	(SUB FOR R34896) (ORDER AR67783 PACKING KIT)
44	AR44883	1	COVER	(MARKED R34120) (SUB FOR AR40453)
45	R26755	2	WASHER	-
46	R27091	2	PIN	-
47	R40149	1	LOCKING COLLAR	(SUB FOR R27090)
48	R40531	1	SPRING	(SUB FOR R26419)
49	R27089	1	NUT	-
50	-	1	Part 52	(SUB FOR R26760) (ORDER AR67783 PACKING KIT)
51	R34121	1	PISTON	-
52	R26485	1	BACK-UP RING	-
53	R495R	1	O-Ring	-
54	R26286	1	O-Ring	-
55	AR39668	1	TEE FITTING	(SUB FOR AR30762)
..	AR39585	1	KIT	KIT, STEERING PISTON CYLINDER AND VALVE ASSEMBLY OVERHAUL (CONTAINS (ALL THE NECESSARY O-RINGS, PACKING, BACK-UP RINGS, PAPER WASHERS, AND OIL SEAL TO COMPLETELY OVERHAUL THE STEERING UNIT)
..	AR67783	1	O-RING KIT	PACKING CONSISTS OF KEYS 23, 43 AND 50, (SUB FOR AR42009)
