DISTRIBUTOR, COIL, SPARK PLUG CABLES, AND SPARK PLUGS [02C04]

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	R26862	1	BRACKET	-
2	R26409	3	GROMMET	-
3	AR50270	1	CABLE	(SUB FOR AR28060)
4	R26861	4	BOOT	-
5	AA4053R	4	SPARK PLUG	(A) (CHAMPION)
5	TY6074	4	SPARK PLUG	(A) (PRESTOLITE) (SUB FOR AA6332R OR AR14019)
5	AR26544	4	SPARK PLUG	(CHAMPION) (SUB FOR AR26543 OR AR26545) (JD500)
5	TY6073	4	SPARK PLUG	(B) (PRESTOLITE) (SUB FOR AR26409 OR AR14021)
6	R44302	1	Tie Band	(SUB FOR R1662R)
7	A3539R	5	ELEC. CONNECTOR ACCESSORY	-
8	-	1	Part 11	(SUB AR11162) (SUB FOR AR11145) (JD500)
8	-	1	Part 12	(SUB AR11162) (DELCO-REMY NO. 1112674) (JD500A*, (JD500A&, JD500B)
9	14H1076	2	Nut	3/8", (HS SAE 8)
10	12H304	2	Lock Washer	3/8"
11	A4157R	2	CLAMP	-
12	R56481	2	STUD	3/8" X 1-1/2", (SUB FOR R26117 OR M3636T)
13	F2632R	1	GASKET	-
14	19H1813	2	CAP SCREW	5/16" X 5/8"
14	12H303	2	Lock Washer	5/16"
15	24H1136	2	Washer	11/32" X 11/16" X 0.065"
16	AR46064	1	ELECTRICAL COIL	(6-VOLT) (DELCO-REMY NO. 1115380 OR 1115202) (SUB FOR AM791T OR AM373T)
17	-	1	Part 22	203MM (8") (MAKE FROM RE11154) (SUB FOR AR26392 OR AR30963) (JD500A*)
17	R11269	1	WIRING LEAD	(JD500B)
18	A4159R	1	BOOT	-
19	14H631	2	Nut	0.190"
19	12H246	2	LOCK WASHER	0.190", (SUB FOR 1909206)
..	AR46273	1	CABLE	(JD500A&, JD500B)
..	-	1	Part 28	(AR46274 NO LONGER AVAILABLE) (SUB (4) AR46273) RADIATION SUPPRESSION SPARK PLUG CABLE FOR USE WITH RADIO (JD500A&, JD500B)

DISTRIBUTOR, COIL, SPARK PLUG CABLES, AND SPARK PLUGS [02C04]

Нет текстового описания
