DIFFERENTIAL LOCK VALVE OIL PIPES (SERIAL NO. 68000- ) [01H09]

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	R30903	1	O-Ring	-
2	R39597	1	ADAPTER FITTING	-
3	-	1	Part 3	DIFFERENTIAL LOCK VALVE TO QUILL, INNER ( AR33967 NO LONGER AVAILABLE)
4	T16911	1	SHIM	-
5	-	1	Part 5	( AR39650 NO LONGER AVAILABLE)
6	R26287	1	O-Ring	-
7	AR36105	1	FITTING	-
8	AR34788	1	LINE	DIFFERENTIAL LOCK VALVE TO QUILL, OUTER
9	19H2284	1	Cap Screw	3/8" X 7/8"
9	12H304	1	Lock Washer	3/8"
10	R34933	2	CLAMP	-
11	R34298	1	STUD	-
12	19H2553	1	Cap Screw	3/8" X 2-5/8"
13	R34933	2	CLAMP	-
14	28H1497	1	Bushing	3/8" X 1-1/2"
15	AR26771	1	ELBOW FITTING	-
16	R26286	1	O-Ring	-
17	AR26771	1	ELBOW FITTING	-
18	R26286	1	O-Ring	-
19	AR30762	1	Tee Fitting	(SUB FOR R27272)
20	R26286	1	O-Ring	-
21	AR34789	1	LINE	DIFFERENTIAL LOCK VALVE TO BRAKE PRESSURE TEE
22	19H2023	1	CAP SCREW	3/8" X 3-1/4"
22	12H304	1	Lock Washer	3/8"
23	T14264	1	Clamp	-
24	T14264	1	Clamp	(NOT EXACTLY AS ILLUSTRATED)
25	28H207	1	Bushing	3/8" X 2-3/4"
26	R26287	1	O-Ring	-
27	AR39795	1	Tee Fitting	-
28	-	1	Part 30	DIFFERENTIAL LOCK RETURN, (COLLAR SHIFT) ( AR34791 NO LONGER AVAILABLE)
28	-	1	Part 31	DIFFERENTIAL LOCK RETURN, (POWER SHIFT) ( AR34792 NO LONGER AVAILABLE)
