REVERSE BRAKE HOUSING AND PISTON (WITH REVERSER) [01E13]

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	T22928	1	SHAFT	(WITH BUSHING)
2	26H77	1	Shaft Key	3/16" X 3/4", (REAR 1000 R.P.M. PTO OR MID PTO)
3	T22126	1	GEAR	(30 TEETH) (REAR 1000 R.P.M. PTO OR MID PTO)
4	R39081	1	Snap Ring	(REAR 1000 R.P.M. PTO OR MID PTO)
5	R41041	1	CAP SCREW	-
7	R39224	1	DOWEL PIN	-
8	AR63139	1	HOUSING	(WITH PINS) (MARKED R39312)
8	AR39163	1	HOUSING	(WITH PINS) (MARKED R39312)
9	19H3483	7	Cap Screw	3/8" X 1-1/8"
10	R39166	1	PIN	(HIGH SPEED LOCKOUT ARM)
11	R39117	1	WASHER	-
12	R33059	1	SEALING WASHER	-
13	R39189	1	PISTON	-
14	R30587	3	Dowel Pin	-
15	AR69661	1	STEERING GEAR	(13 TEETH) (MARKED R57956) (SUB AR96662) (SUB FOR AR39164, THIS APPLICATION)
15	R57957	1	GEAR	(USE WITH AR96662) (26 TEETH)
16	R112877	5	Cap Screw	-
17	JD8720	1	CYLINDRICAL ROLLER BEARING	-
6A	-	1	Part 6	(SUB AR96662) (SUB FOR AR39107, THIS APPLICATION) (MARKED R39244)
6B	AR96662	1	OIL PUMP	(MARKED R57959)

REVERSE BRAKE HOUSING AND PISTON (WITH REVERSER) [01E13]
