SHORT BLOCK INSTALLATION KIT (6619A) (EARLIEST DESIGN W/AR99344) (ENGINE SERIAL NO. -039978) [02C11]

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	R71732	2	O-Ring	-
2	AR94479	1	OIL PUMP	(USE WITH R71505) (SUB RE60622 AND RE43167, APPL)
2	AR99344	1	OIL PUMP	(USE WITH R74463) (SUB FOR AR96193) (SUB RE60622 AND RE43167, APPL)
3	19H2733	2	Cap Screw	3/8" X 2-3/8"
4	M72490	5	Washer	(SUB FOR R42729)
5	19H1765	3	Cap Screw	3/8" X 1-3/4"
6	R57696	4	Washer	-
7	19H2549	2	Cap Screw	3/8" X 1-7/8"
8	19H3219	2	Cap Screw	3/8" X 1-3/8"
9	R62938	1	Gear	-
10	T21242	1	Washer	-
11	14H826	1	Nut	1/2"
12	-	1	Part 13	(NLA)
13	-	2	Part 14	NOT REQUIRED
14	-	2	Part 15	NOT REQUIRED
15	22H1040	1	Set Screw	5/16" X 1-1/4"
16	14H785	1	Nut	5/16"
17	R70223	1	BRACKET	-
18	R71505	1	ELBOW FITTING	(USE WITH AR94479)
19	R70224	1	BRACKET	-
20	M72490	10	Washer	10.300 X 21 X 2.500 MM (0.406" X 0.827" X 0.098") (SUB FOR R70234 OR R42729)
21	19H2665	3	Cap Screw	3/8" X 1-5/8"
22	RE29234	1	HOUSING	(SUB FOR AR80682)
23	R54123	1	Adapter Fitting	-
24	M63440	1	LOCK NUT	(SUB FOR C744DN)
25	AR99953	1	Oil Pump Intake	(USE WITH R74463)
26	R74463	1	Elbow Fitting	(USE WITH AR94479)
27	19H3239	3	Cap Screw	3/8" X 1-1/4"
28	R62947	1	Tube	-
29	R62948	1	ELBOW FITTING	-
30	19H3483	3	Cap Screw	3/8" X 1-1/8"
31	AR102887	1	KIT	(SUB RG23549 AND RE43167)

SHORT BLOCK INSTALLATION KIT (6619A) (EARLIEST DESIGN W/AR99344) (ENGINE SERIAL NO. -039978) [02C11]
