Light Kit, Loader/Auxiliary Driving Lights

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	RE229111	2	Headlight	RH
2	57M7166	2	Bulb	12V
3	L79050	2	Dust Shield	-
4	R308935	1	Bracket	LH
4	R308936	1	Bracket	RH
5	RE229124	2	Headlamp Wiring Harness	-
6	AH225366	2	Clip	-
7	19M9356	4	Screw	M8 X 30, Outer Mirror Support Spacer to Cab LH/RH
7	19M10361	4	Socket Head Screw	M8 X 35, Use With Mirror, Handrail and Auxiliary Drive Lights LH/RH
8	19M7866	1	Screw	M8 X 20
9	19M9357	1	Screw	M8 X 16, Use With Mirror, Beacon Light and Grab Handle LH
10	RE300747	1	Roof Wiring Harness	-
11	57M8129	1	Elec. Connector Terminal	-
11	57M8839	1	Elec. Connector Housing	Right Front Inner Flood Light USE WITH (2) 57M7297_Pins, (2) 57M10915_Seals
12	57M7255	1	Elec. Connector Housing	Right Loader Light USE WITH (3) R104846_Pins, (3) 57M7258_Seals
12	57M7317	1	Elec. Connector Accessory	-
13	M135518	1	Electrical Connector Assy	Inline to Roof USE WITH (0) 57M9203_Pins, (6) R104921_Seals
13	57M8327	1	Electrical Connector Assy	-
14	57M8839	1	Elec. Connector Housing	Left Front Inner Flood Light USE WITH (2) 57M7297_Pins, (2) 57M10915_Seals
14	57M8129	1	Elec. Connector Terminal	-
15	57M7255	1	Elec. Connector Housing	Left Loader Light USE WITH (3) 57M10770_Pins, (3) 57M7258_Seals
15	57M7317	1	Elec. Connector Accessory	-
16	57M7257	1	Elec. Connector Housing	USE WITH (3) R104909_Pins, (3) 57M7258_Seals
16	57M7290	1	Elec. Connector Accessory	-
16	RWA10714	3	Repair Wire Assembly	Cavity A, B and C
17	57M9229	2	Clip	-

Light Kit, Loader/Auxiliary Driving Lights

Нет текстового описания
