Propulsion Drive Countershaft, Regular Belt Drive ( - 115000)

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	14H1039	5	Nut	5/8"
1	14H794	6	Nut	3/4"
1	14H1039	6	Nut	5/8"
2	H75842	2	Eyebolt	-
2	H85565	2	Eyebolt	-
3	24H1626	1	Washer	21/32" X 2" X 0.060"
4	H75851	1	Cap Screw	-
5	H23222	2	Bushing	-
5	H85568	2	Bushing	-
6	AH75352	1	Arm	(MARKED H75840) (SUB AH83540)
6	AH83540	1	Arm	(MARKED H83459) (SUB AH86618)
6	AH86618	1	Arm	(MARKED H85567) (SUB AH86829)
6	AH86829	1	Arm	UPPER, WITH BUSHINGS (MARKED H85845)
7	JD7806	1	Lubrication Fitting	90°, 1/4"
8	24H1667	1	Washer	1-17/64" X 2-1/4" X 0.075"
11	24H1305	3	Washer	13/32" X 13/16" X 0.065"
11	24H1305	4	Washer	13/32" X 13/16" X 0.065"
11	24H1305	2	Washer	13/32" X 13/16" X 0.065"
12	14H812	1	NUT	3/8"
12	19H1732	1	Cap Screw	3/8" X 1-1/4"
13	H75850	4	Bushing	-
14	14H812	2	NUT	3/8"
14	19H2104	2	Cap Screw	3/8" X 5"
15	12H236	1	Lock Washer	3/4"
15	12H294	1	Lock Washer	5/8"
16	19H1733	1	CAP SCREW	3/8" X 2-1/2"
9A	AH86640	1	Support	(SUB AH87271, (2) H85565, 12H236, 14H794, 19H1733 AND 19H1944)
9A	AH80493	1	Support	(SUB AH86640)
9B	AH87271	1	Support	-
9B	AH86617	1	Support	(SUB AH87271)
10A	14H812	2	NUT	3/8"
10A	19H2128	2	CAP SCREW	3/8" X 3"
10B	19H1944	2	Cap Screw	3/8" X 2-3/4"

Propulsion Drive Countershaft, Regular Belt Drive ( - 115000)
