JOYSTICK HYDRAULIC STEERING KIT (2 OF 2)

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	-	1	Part 1	Additional Components Listed on Previous Page, (AT335888 NLA)
2	19M7774	7	Screw	M6 X 12
3	14M7397	4	Lock Nut	M6
4	19M7786	4	Screw	M10 X 30
5	19M7866	4	Screw	M8 X 20
6	37M7340	6	Bolt	-
7	AT308199	1	Seat Belt	3 in.
8	AT310435	1	Seat	-
9	AT311997	1	Bracket	-
10	AT338486	1	Armrest	(SUB FOR AT313374)
11	AT314833	1	Cover	-
12	AT331844	1	Bracket	-
13	AT330670	1	Bracket	-
14	N119177	1	GROMMET	-
15	T209539	1	Cover	-
16	T214514	1	Label	Joystick Steering
17	AT311621	1	Wiring Harness	Joystick Steering
18	AT311633	1	Toggle/Rocker Switch	Joystick Steering Switch
19	AT365217	1	Electrohydraulic Controller	(SUB FOR AT341273 OR AT345513)
20	-	1	Part 20	(NSEP) (SUB AT311997)
21	19M9478	1	Screw	M5 X 16
22	R44302	1	Tie Band	-
23	-	1	Part 23	(NSEP)
24	-	1	Part 24	(NSEP)
25	-	1	Part 25	(NSEP)
26	-	1	Part 26	(NSEP)
27	-	1	Part 27	(NSEP)
28	-	1	Part 28	(NSEP)
29	-	1	Part 29	-
30	AT321224	1	Push Switch	-
31	AT227063	2	Lever	-
32	24M7036	2	Washer	9 X 16 X 1.600 mm
33	T215154	3	Screw	M6 X 12
34	AT325670	1	Cover	-
35	AT325671	1	Cover	-
36	AT325677	1	Package Of Parts	-
37	AT325669	1	Cover	-
38	AT325667	1	Knob	-
39	AT325664	1	Knob	-
40	AT325663	1	Lever	-
41	AT325662	1	Handle	-
42	AT325661	1	Bracket	-
43	AT341684	1	Armrest Kit	-
44	AT325659	1	Armrest Kit	-
45	AT341683	1	Pivot	-
46	AT325665	1	Spacer	-
47	AT325666	1	Bracket	-
48	AT325668	1	Pin	-
49	AT330808	1	Bracket	-
