PRESSURE REDUCING VALVE (740A GRAPPLE SKIDDER) [03C07]

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	R26448	1	O-Ring	-
2	R31698	1	SPRING	(SUB R79134 AND R74418, THIS APPLICATION)
2	R74418	1	Spring	-
3	R86770	1	HOUSING	(SUB FOR R64503 AND R79133)
4	R46866	1	PIN FASTENER	-
5	F3396R	1	Snap Ring	(USE WITH F3392R)
6	R26650	1	Dowel Pin	-
7	R79135	2	STRAP	(SUB FOR R46902)
8	R26385	1	PIN FASTENER	HEADED
9	24H1311	2	Washer	13/32" X 1-1/4" X 0.220"
10	AR82448	1	HANDLE	-
11	R26386	2	SNAP RING	-
12	11M7059	1	Cotter Pin	3.200 X 20 MM
13	F3353R	1	O-Ring	-
14	R86162	1	PLUNGER	(SUB FOR R68648) (ALSO ORDER R55081)
15	F2962R	1	SPRING ASSEMBLY	-
17	R55081	1	Needle Roller	(SUB FOR R43244, THIS APPLICATION)
18	R46855	1	SPOOL VALVE	(SUB R79134 AND R74418)
18	R79134	1	VALVE	(SUB FOR R46855 AND R74417) (SUB R82134 AND (11) R82133)
18	R82134	1	VALVE	-
18	R85362	1	VALVE	-
19	R27216	1	DRAIN PLUG	-
20	R26287	1	O-Ring	-
21	R27094	1	Drain Plug	-
22	R26286	1	O-Ring	-
23	-	1	Part 29	( AR82447 NO LONGER AVAILABLE) (SUB RE26463 IF AVAILABLE)
24	R28037	2	SPACER	-
25	24H1254	2	Washer	17/32" X 1-1/8" X 0.105"
26	19H3550	1	Cap Screw	1/2" X 4"
27	19H1840	1	CAP SCREW	1/2" X 5-1/2"
16A	R82133	1	SHIM	0.51 MM (.020") (SUB FOR R46901)
16B	B1664R	1	SHIM	0.76 MM (.030")
16B	R82133	1	SHIM	0.51 MM (.020")

PRESSURE REDUCING VALVE (740A GRAPPLE SKIDDER) [03C07]
