Открытый узел

70 Hydraulic Pumps, Rockshaft and SCV

Серийный номер

Бренд

John Deere

Читать описание

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
-	-	1	Pin Fastener, Centre Link Bracket	-
-	-	1	Hydraulic Pump Drive	-
-	-	1	Hydraulic Quick Couplers	-
-	-	1	Lift Links With Hook - Type Draft Links	-
-	-	1	M-SCV, 100 Series	-
-	-	1	Mechanically Operated Control Valve, M-SCV, 200 Series Position III	-
-	-	1	Mechanically Operated Control Valve, M-SCV, 200 Series Position IV	-
-	-	1	Mounting Parts, Charge Pump, W/O Additional Oil Reservoir, Hydraulic Pump 45 cm³	-
-	-	1	Mounting Parts, Inlet Priority Valve - 2	-
-	-	1	Oil Lines, Charge Pump	-
-	-	1	Oil Lines, Lift Cylinder	-
-	-	1	HYDRAULIC PUMP (45CM3)	-
-	-	1	Plugs / Fittings, Hydraulic Pump 45 cm³	-
-	-	1	Plugs, Priority Valve W/ ICV	-
-	-	1	Position Sensor, Rockshaft	-
-	-	1	Release Cable, Center Link, W/ Hook	-
-	-	1	Release Cable, Draft Link Hook Type	-
-	-	1	Rockshaft	-
-	-	1	Rockshaft Control Valve, W/ Stepper Motor	-
-	-	1	Stop, Sway Limitation, Stabilizer Bar	-
-	-	1	Valve, Priority 2+3	-
-	-	1	Wearing Plates, Draft Links W/ Hook	-
-	-	1	End Cover, Position IV, RH	-
-	-	1	Brace, Stabilizer Bar, RH	-
-	-	1	Bracket, Center Link	-
-	-	1	Center Link Bracket, Category 3	-
-	-	1	Center Link, Hook Type, Category 3	-
-	-	1	Charge Pump, Hydraulic Pump 45 cm³	-
-	-	1	Draft Link Support Shaft	-
-	-	1	Draft Links W/ Hook	-
-	-	1	Dust Protection Shields, Quick Couplers	-
-	-	1	End Cover, Position II, LH	-
-	-	1	End Cover, Position III, RH	-
-	-	1	Brace, Stabilizer Bar, LH	-
-	-	1	End Cover, W/O Rear Hitch Valve, RH	-
-	-	1	Fittings, Priority 2, W/O TLS™	-
-	-	1	Hitch Ball, W/ Reducing Bushing, Category 3 / 2	-
-	-	1	Holder, Release Cable, Cab	-
-	-	1	Hoses, Hydraulic Filter	-
-	-	1	Hydraulic Lift Cylinders	-
-	-	1	Hydraulic Oil Filter	-
-	-	1	Hydraulic Oil Reservoir Lines	-
-	-	1	Hydraulic Oil Reservoir, Oil Lines	-

70 Hydraulic Pumps, Rockshaft and SCV

Нет текстового описания
