PILOT CONTROL HOSES, PRESSURE REDUCING VALVES, CHECK VALVES AND FILTER [02E22]

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	R26448	9	O-Ring	(SUB FOR T70177)
2	38H1160	5	Adapter Fitting	-
3	T77613	10	O-Ring	-
4	AT81931	3	Hydraulic Hose	11/16" X 515 MM (20-1/4") X 11/16", (SUB FOR AT83751)
5	AT79763	1	HYDRAULIC HOSE - FABRICATE	11/16" X 1 440 MM (56-3/4") X 11/16"
6	N189220	1	Tie Band	(SUB FOR (AR) AA21510)
7	AT81867	2	Check Valve	-
8	T104377	1	PORT PLATE	-
9	19M7803	2	Screw	M8 X 70, (SUB FOR AT211859 OR CH19100)
10	28H1597	1	Washer	0.546" X 0.840" X 3/8"
11	38H1004	1	Elbow Fitting	-
12	38H1067	1	Adapter Fitting	-
13	AT68904	1	HYDRAULIC PRESSURE VALVE	-
14	19H2333	2	Cap Screw	1/4" X 2-1/4"
15	28H1514	2	SPACER	0.364" X 0.540" X 9/16"
16	14H786	2	Nut	1/4"
17	38H1016	1	Tee Fitting	-
18	AT79568	1	HYDRAULIC HOSE - FABRICATE	11/16" X 813 MM (32") X 13/16"
19	T77857	2	O-Ring	-
20	38H1024	1	Tee Fitting	-
21	R47150	1	O-Ring	-
22	38H1416	1	Fitting	-
23	-	1	Part 23	(SUB AT105480)
24	H63289	1	O-Ring	-
25	-	1	Part 25	(SUB AT105419)
26	-	1	Part 26	(SUB AT105419)
27	-	1	Part 27	(SUB AT105419)
28	R29936	1	O-Ring	-
29	T114718	1	FITTING PLUG	-
30	AT105419	1	KIT	-
31	AT115276	1	HYDRAULIC FILTER	(SUB FOR AT105480)

PILOT CONTROL HOSES, PRESSURE REDUCING VALVES, CHECK VALVES AND FILTER [02E22]

Нет текстового описания
