DECALS AND LABELS KIT (670A AND 672A) [02C09]

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	JD5621	1	LABEL	LEAPING DEER
1	JD5623	1	LABEL	LEAPING DEER
2	JD5616	2	LABEL	NAME
3	T43461	1	SAFETY SIGN	SAFETY
4	R48628	1	LABEL	OIL FILLER CAP
5	T43832	1	LABEL	RIPPER
6	T46589	1	LABEL	CONTROL IDENTIFICATION
7	T47545	1	LABEL	WIPER
8	T48534	1	LABEL	DIRECTION INDICATOR
9	T43471	1	LABEL	START
9	T62122	1	LABEL	START AID
10	T43458	1	LABEL	SHIFT SELECTOR
11	T50132	1	LABEL	THROTTLE
12	T128277	1	LABEL	INSTRUCTION, TRANSMISSION OIL LEVEL (SUB FOR T38004)
13	U42958	1	SAFETY SIGN	SAFETY
14	R56902	1	Label	DRY AIR CLEANER
15	U42957	1	SAFETY SIGN	SAFETY
16	T43470	1	LABEL	AIR FILTER RESTRICTION
17	T43459	1	LABEL	PARKING BRAKE RELEASE
18	T35672	1	LABEL	START AND STOP PROCEDURE
19	JD5602	1	LABEL	LEAPING DEER, (SUB FOR JD5272)
20	T43705	1	SAFETY SIGN	CAUTION
21	-	1	Part 23	CAUTION ( T58344 NO LONGER AVAILABLE SEE PARTS BULLETIN DS86-24 (03APR86))
22	T62688	1	LABEL	ASSIST HANDLE
23	T61248	1	LABEL	FILTER GAUGE
24	T61249	1	LABEL	IMPORTANT
25	T44647	1	LABEL	TURN SIGNAL
26	AT63242	1	BEARING KIT	SEAT WEIGHT DECALS
27	-	2	Part 29	BATTERY CONNECTION AND PRECAUTION ( T23616, NO LONGER AVAILABLE)
28	T66950	1	LABEL	FRONT SENSOR
29	T52885	1	LABEL	REAR AUXILIARY VALVE
30	T52884	1	LABEL	ONE FUNCTION VALVE
31	T49256	1	LABEL	REAR STEER INDICATOR
32	T42170	1	Label	INSTRUCTIONAL
33	T45316	1	LABEL	ENGLISH
34	T45315	1	LABEL	FUSES, ENGLISH
35	T146102	1	Label	START SAFETY, (SUB FOR T75512, T146102 OR T146102 OR T146102)
36	AT70070	1	LABEL KIT	ENGLISH / REFINISHING

DECALS AND LABELS KIT (670A AND 672A) [02C09]
