LOW SHAFT SPEED INDICATOR - CONTINUED (7501 - )

Серийный номер

Бренд

John Deere

Читать описание

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
19	22H841	1	Set Screw	(PARTS IDENTIFIED BY AN (B) ARE CONTAINED IN AH86865 SHAFT INDICATOR CONVERSION KIT TO) 1/4" X 1/4"
20	JD8551	1	Eccentric Locking Collar	(STRAW CHOPPER)
21	H83615	1	Bracket	(PARTS IDENTIFIED BY AN (A) ARE CONTAINED IN AH86864 SHAFT INDICATOR CONVERSION KIT TO) (PARTS IDENTIFIED BY AN (B) ARE CONTAINED IN AH86865 SHAFT INDICATOR CONVERSION KIT TO) (STRAW WALKER)
21	H83615	1	Bracket	(STRAW CHOPPER)(MACHINES EQUIPPED WITH NEW STRAW CHOPPER USE H92145)
21	H83615	1	Bracket	(STRAW WALKER) (SUB H100540)
21	H100540	1	Bracket	(STRAW WALKER)
21	H92145	1	Bracket	(NEW STRAW CHOPPER) (SUB H100539)
21	H100539	1	Bracket	(NEW STRAW CHOPPER)
22	AH83763	1	Wiring Harness	(PARTS IDENTIFIED BY AN (A) ARE CONTAINED IN AH86864 SHAFT INDICATOR CONVERSION KIT TO) (1 USED-REGULAR; 2 USED-DIP AND POUR ELEVATOR)
23	H100541	1	Bracket	(CLEAN GRAIN ELEVATOR AND CONVEYOR AUGER) (2 USED-REGULAR; 1 USED-DIP AND POUR ELEVATOR)
23	H83616	1	Bracket	(PARTS IDENTIFIED BY AN (B) ARE CONTAINED IN AH86865 SHAFT INDICATOR CONVERSION KIT TO) (CLEAN GRAIN ELEVATOR AND CONVEYOR AUGER) (2 USED-REGULAR; 1 USED-DIP AND POUR ELEVATOR) (SUB H100541)
23	H83616	2	Bracket	(PARTS IDENTIFIED BY AN (B) ARE CONTAINED IN AH86865 SHAFT INDICATOR CONVERSION KIT TO) (CLEAN GRAIN ELEVATOR AND CONVEYOR AUGER)
25	H83617	1	Bracket	PULSE PICKUP (TAILINGS ELEVATOR) (SUB H113058)
25	H113058	1	Bracket	-
26	AH80881	1	Wiring Harness	(WARNING SYSTEM)
27	H80181	1	Seal	(CONTROL BOX COVER)
28	M66044	9	Tie Band	(SUB FOR R44302)
28	M66044	4	Tie Band	-
29	21H1014	1	Screw	1/4" X 1"
29	14H786	1	Nut	1/4"
30	AH78158	1	Switch	DELAY (SEPARATOR LEVER)
31	H80180	1	Actuator	ACTUATOR (SEPARATOR LEVER)
32	AH11015	3	Clip	-
33	H80179	1	Bracket	-
34	19H1948	1	Cap Screw	1/4" X 3/4"
34	14H786	1	Nut	1/4"
35	AM3208T	1	Fuse Holder	-
18A	AH83762	1	Clamp	(1 USED-REGULAR; 2 USED-STRAW CHOPPER) (SUB AH84986)
18B	AH84986	1	Clamp	(PARTS IDENTIFIED BY AN (A) ARE CONTAINED IN AH86864 SHAFT INDICATOR CONVERSION KIT TO) (PARTS IDENTIFIED BY AN (B) ARE CONTAINED IN AH86865 SHAFT INDICATOR CONVERSION KIT TO) (1 USED-REGULAR; 2 USED-STRAW CHOPPER) (SUB AH91336)
18B	AH91817	1	Clamp	(STRAW CHOPPER)
18B	AH91336	1	Clamp	-
18B	AH91336	1	Clamp	(4 USED-REGULAR; 2 USED- STRAW CHOPPER) (MACHINES EQUIPPED WITH NEW STRAW CHOPPER USE AH91817)
24A	AH83760	3	Clamp	(SUB AH84986)
24B	AH91336	1	Clamp	MAGNETIC (3 USED-REGULAR; 2 USED-DIP AND POUR ELEVATOR)
24B	AH84986	1	Clamp	(PARTS IDENTIFIED BY AN (A) ARE CONTAINED IN AH86864 SHAFT INDICATOR CONVERSION KIT TO) (PARTS IDENTIFIED BY AN (B) ARE CONTAINED IN AH86865 SHAFT INDICATOR CONVERSION KIT TO) (3 USED-REGULAR; 2 USED-DIP AND POUR ELEVATOR) MAGNETIC (SUB AH91336)
24B	AH84986	3	Clamp	(PARTS IDENTIFIED BY AN (A) ARE CONTAINED IN AH86864 SHAFT INDICATOR CONVERSION KIT TO) (PARTS IDENTIFIED BY AN (B) ARE CONTAINED IN AH86865 SHAFT INDICATOR CONVERSION KIT TO) MAGNETIC

LOW SHAFT SPEED INDICATOR - CONTINUED (7501 - )
