FRONT CONSOLE CONTROLS WITH SCARIFIER ( - 529197)

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	AT158538	1	Knob	RIGHT BLADE LIFT (KNOB WITH SYMBOL), (SUB FOR T115213 AND T115298)
2	14H732	9	Nut	3/8"
3	T187847	3	Lever	(SUB FOR T104384)CIRCLE SIDE SHIFT, WHEEL LEAN AND RIGHT-HAND BLADE LIFT
4	AT49297	17	Link End	-
5	14H882	25	Nut	5/16"
6	19H2705	17	Cap Screw	5/16" X 1"
7	T104482	3	Bushing	(SUB FOR T103436)
8	24H1390	1	Shim	SHIMS FOR END PLAY
9	T104220	34	Washer	-
10	T40189	3	Snap Ring	-
11	T82760	2	Eyebolt	-
12	T82715	1	Eyebolt	-
13	T82759	2	Eyebolt	-
14	T82758	2	Eyebolt	-
15	T82757	2	Eyebolt	-
16	T82760	1	Eyebolt	-
17	T187848	2	Lever	(SUB FOR T104385)
18	AT158539	1	Knob	SCARIFIER (KNOB WITH SYMBOL), (SUB FOR T115213 AND T115297)
19	AT158537	1	Knob	WHEEL LEAN (KNOB WITH SYMBOL), (SUB FOR T115213 AND T115296)
20	AT158536	1	Knob	REAR STEERING (KNOB WITH SYMBOL), (SUB FOR T115213 AND T115295)
21	AT158535	1	Knob	CIRCLE SIDESHIFT (KNOB WITH SYMBOL), (SUB FOR T115213 AND T115294)
22	T187845	3	Lever	(SUB FOR T104382)
23	AT158534	1	Knob	CIRCLE ROTATE (KNOB WITH SYMBOL), (SUB FOR T115213 AND T115293)
24	T187846	1	Lever	(SUB FOR T104383)
25	AT158533	1	Knob	BLADE TILT (KNOB WITH SYMBOL), (SUB FOR T115213 AND T115292)
26	AT158532	1	Knob	BLADE SIDESHIFT (KNOB WITH SYMBOL), (SUB FOR T115213 AND T115291)
27	T104483	1	Bushing	(SUB FOR T103438)
..	-	1	Part 28	TO CONVERT TO OFFSET BLADE LIFT LEVER ( AT85176 - NO LONGER AVAILABLE), (SUB (4) T104220, (2) T187851 AND T82716)

FRONT CONSOLE CONTROLS WITH SCARIFIER ( - 529197)

Нет текстового описания
