GRAPPLE TONGS AND CROSSLINKS

Нет текстового описания

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	T143299	4	Bushing	(648E) (USE WITH 10.0 SQ. FT. GRAPPLE AND TONG), (SUB FOR T125175)
1	T143299	4	Bushing	(648E AND 748E) (USE WITH 11.5 SQ. FT. GRAPPLE AND TONG), (SUB FOR T125175)
1	T143106	4	Bushing	(748E) (USE WITH 14.5 SQ. FT. GRAPPLE AND TONG), (SUB FOR T125177)
1	T143299	8	Bushing	(548E) (USE WITH 8.0 SQ. FT. GRAPPLE AND TONG), (SUB FOR T125175)
2	AT162495	1	Tong	(748E) (14.5 SQ. FT.) (L.H.)
2	AT162490	1	Tong	(648E AND 748E) (11.5 SQ. FT.) (L.H.)
2	-	1	Part 9	(648E) (10.0 SQ. FT.) (L.H.), ( AT162488 NLA)
2	AT157642	1	Tong	(748E) (14.5 SQ. FT.) (L.H.)
2	AT157573	1	Tong	(648E AND 748E) (11.5 SQ.FT.) (L.H.)
2	AT157639	1	Tong	(648E) (10.0 SQ. FT.) (L.H.)
2	-	1	Part 5	( AT158067 NLA) (548E) (8.0 SQ. FT.) (L.H.), (SUB FOR AT158067)
3	T162396	4	Lubrication Fitting	(548E, 648E AND 748E), (SUB FOR JD7798 (SELF TAPPING))
4	T144192	2	Pin Fastener	(548E) (USE WITH 8.0 SQ. FT. GRAPPLE AND TONG) (2.144 - 2.146 IN.)
4	T144192	2	Pin Fastener	(648E) (USE WITH 10.0 SQ. FT. GRAPPLE AND TONG) (2.144 - 2.146 IN.)
4	T144192	2	Pin Fastener	(648E AND 748E) (USE WITH 11.5 SQ. FT. GRAPPLE AND TONG) (2.144 - 2.146 IN.)
4	T144193	2	Pin Fastener	(748E) (USE WITH 14.5 SQ. FT. GRAPPLE AND TONG)
5	AT157574	1	Tong	(648E AND 748E) (11.5 SQ.FT.) (R.H.)
5	AT162491	1	Tong	(648E AND 748E) (11.5 SQ. FT.) (R.H.)
5	AT162496	1	Tong	(748E) (14.5 SQ. FT.) (R.H.)
5	AT162489	1	Tong	(648E) (10.0 SQ. FT.) (R.H.)
5	AT157641	1	Tong	(748E) (14.5 SQ.FT.) (R.H.)
5	AT157640	1	Tong	(648E) (10.0 SQ. FT.) (R.H.)
5	AT158068	1	Tong	(548E) (8.0 SQ. FT.) (R.H.), (SUB FOR AT136179)
6	T139809	2	Link	(548E) (8.0 SQ. FT.)
6	AT158664	1	Link	(648E) (10.0 SQ. FT.) FRONT (SUB FOR AT150069)
6	AT158664	1	Link	(648E AND 748E) (11.5 SQ. FT.) FRONT (SUB, FOR AT150069)
6	AT150074	1	Link	(748E) (14.5 SQ. FT.) FRONT
6	AT158665	1	Link	(648E) (10.0 SQ. FT.) REAR (SUB FOR AT150071)
6	AT158665	1	Link	(648E AND 748E) (11.5 SQ. FT.) REAR (SUB, FOR AT150071)
6	AT150076	1	Link	(748E)(14.5 SQ.FT.) REAR
7	19M8198	4	Cap Screw	M10 X 175, (548E, 648E AND 748E)
8	24M7239	8	Washer	10.700 X 21 X 2.500 mm, (548E, 648E AND 748E)
9	14M7274	4	Nut	M10, (548E, 648E AND 748E)
10	T143106	4	Bushing	(648E)(10.0 SQ. FT.), (SUB FOR T125175)
10	T143106	4	Bushing	(648E AND 748E) (11.5 SQ. FT.) (14.5 SQ. FT), (SUB FOR T125175)
10	T143299	4	Bushing	(548E) (8.0 SQ. FT.) (SUB FOR T125175)
