MAIN HYDRAUALIC PUMP REGULATOR COVER [02B13]

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	0215017	18	Fitting Plug	(SUB FOR TH101445)
2	0215016	3	Fitting Plug	(SUB FOR TH101444)
3	-	1	Part 3	(INCLUDES PISTONS ON KEYS 22 AND 23) ( TH108160 NO LONGER AVAILABLE)
4	985099	2	O-Ring	(SUB FOR TH101479)
5	0215208	2	RETAINER	(SUB FOR TH101471)
6	CH10571	2	Packing	(SUB FOR TH101478)
7	0215214	2	SPRING	(SUB FOR TH101477)
8	0215207	2	RETAINER	(SUB FOR TH101470)
9	A3917R	2	O-Ring	(SUB FOR TH101480)
10	-	2	Part 10	(SUB TH108161)
11	-	2	Part 11	(SUB TH108161)
12	0215221	4	Pipe Plug	(SUB FOR TH101486)
13	0215222	2	ORIFICE	(SUB FOR TH101487)
14	0215220	2	Fitting Plug	(SUB FOR TH101485)
15	12M7135	8	Lock Washer	10 MM, (SUB FOR TH101449) (SUB FOR 12M6791)
16	M341080	8	BOLT	(SUB FOR TH101483, 0215218)
17	0215205	2	FITTING PLUG	(SUB FOR TH101468)
18	0215224	2	NUT	(SUB FOR TH101489)
19	0215219	2	SET SCREW	(SUB FOR TH101484)
20	0215225	2	CAP	(SUB FOR TH101491)
21	T65954	2	O-Ring	(SUB FOR TH101482)
22	-	2	Part 22	-
23	-	2	Part 23	-
24	0215216	2	O-Ring	(SUB FOR TH101481)
25	0215211	1	RETAINER	(SUB FOR TH101474) (MARKED A)
25	0215212	1	RETAINER	(SUB FOR TH101475) (MARKED B)
25	0215213	1	RETAINER	(SUB FOR TH101476) (MARKED C)
26	0215210	2	Guide	(SUB FOR TH101473)
27	0215223	2	Ball	(SUB FOR TH101488)
28	0215209	2	Fitting Plug	(SUB FOR TH101472)
29	0234904	3	PLUG	(SUB FOR TH101610) (NOT ILLUSTRATED)
30	0215221	2	Pipe Plug	-
31	4206967	1	PLUNGER	(SUB FOR TH108161)
32	M800650	4	Packing	(SUB FOR TH100716)
33	4506408	2	O-Ring	(SUB FOR TH101490)
34	4159966	1	COVER	(SUB FOR TH101430)
35	M800650	1	Packing	-
