BREAKAWAY COUPLER (TRACTOR SERIAL NO. -030271) [04E25]

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	R59633	2	WEAR RING	(SUB FOR R28204)
2	R28085	2	GUIDE	(ORDER AR93819 OR AR93820, THIS APPLICATION)
3	R28084	2	SPRING	-
4	D2361R	2	Ball	13MM (1/2")
5	R27430	1	HYD. QUICK-CONNECT COUPLER	(PRESSURE) (SUB AR93819)
5	R45630	1	HYD. QUICK-CONNECT COUPLER	(RETURN) (SUB AR93820)
6	R28006	2	CAP	-
7	AR30210	1	HYDR.QUICK COUPLER PLUG	(PRESSURE) (SUB AR93819)
7	AR47643	1	BREAKAWAY COUPLER	(RETURN) (SUB AR93820)
8	R34399	2	Snap Ring	-
9	R32356	2	SNAP RING	-
10	R26485	2	BACK-UP RING	-
11	R59343	2	O-Ring	-
12	400R	12	Ball	6MM (1/4")
13	R26484	4	Back-Up Ring	-
14	R65286	4	O-RING	(SUB FOR A3917R, THIS APPLICATION)
15	R34397	2	SOCKET OUTLET	-
16	R375R	2	O-Ring	-
17	R26482	2	Ring	-
18	D2361R	2	Ball	13MM (1/2")
19	R28084	2	SPRING	-
20	R34400	2	PLUG	-
21	R26483	2	SNAP RING	-
22	R34398	2	SLEEVE	-
23	R31890	2	Spring	-
24	R72653	2	Snap Ring	(SUB FOR M2396T)
25	30H15	2	PLUG	1-1/8"
26	AR40827	1	HOUSING	(MARKED R40499) (SUB AR82572, R59629, R65289, R66916, R49187, R27166, R41057, (2) R65501, (2) R65502 AND R74695)
26	AR82572	1	HOUSING	(MARKED R65284)
27	R65285	4	SEAL	(SUB R79311)
28	A4730R	4	O-Ring	(SUB (4) R79311, THIS APPLICATION)
29	R26480	4	BACK-UP RING	(SUB (4) R79311, THIS APPLICATION)
30	R51285	1	PLATE	(SUB AR75958, THIS APPLICATION)
31	AR82576	2	LEVER	(SUB FOR AR33877) (SUB AR99100)
32	AR75958	1	CAM	-
33	12H303	1	Lock Washer	5/16"
34	R49191	1	STUD	-
35	24H1286	1	Washer	9/32" X 1/2" X 1/16"
36	R72654	1	Snap Ring	(SUB FOR R27507)
37	R32419	2	COVER	(SUB R80324)

BREAKAWAY COUPLER (TRACTOR SERIAL NO. -030271) [04E25]
