COUNTERWEIGHT REMOVAL HIGH-PRESSURE HYDRAULIC HOSES

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
0	4240863	1	Flow Control Hyd. Valve	(SUB FOR AT132548)
1	19M7875	2	Cap Screw	M10 X 70
1	12M7066	2	Lock Washer	10 mm
2	4131346	2	Spacer	(SUB FOR AT132491)
3	4240862	1	Manifold	(SUB FOR AT132547)
4	19M8655	2	Cap Screw	M10 X 55
4	12M7066	2	Lock Washer	10 mm
5	4154656	2	Elbow Fitting	(SUB FOR TH101588)
6	AT126482	1	Hydraulic Hose	11.1252" X 500 mm (19-3/4") X 11.1252"
7	4395369	2	Flange Fitting	(SUB FOR TH4395369)
8	T72216	2	O-Ring	-
9	19M8734	8	Screw	M14 X 45
10	94-1703	1	Adapter Fitting	(SUB FOR TH101976)
12	4274178	2	Elbow Fitting	(SUB FOR AT170146)
13	T77857	6	O-Ring	-
14	4220806	1	Flow Control Hyd. Valve	(SUB FOR AT128495)
16	-	4	Part 17	(CTL), (MAKE FROM AT138222)
17	R50454	2	Clamp	(SUB FOR TH109445 OR 4192034)
18	19M8324	1	Cap Screw	M10 X 16
19	12M7066	1	Lock Washer	10 mm
20	4457800	1	Hydraulic Hose	(SUB FOR TH4457800 AND THA853144)
21	4457798	1	Hydraulic Hose	(SUB FOR TH4457798)
22	H77698	4	Tie Band	-
23	4348093	2	Hydraulic Hose	(SUB FOR TH4348093)
24	19M7938	1	Cap Screw	M10 X 20
24	12M7066	1	Lock Washer	10 mm
26	A853144	2	Adapter Fitting	-
26	4506418	2	O-Ring	(SUB FOR U46489)
27	4210942	2	Adapter Fitting	(SUB FOR AT131868)

COUNTERWEIGHT REMOVAL HIGH-PRESSURE HYDRAULIC HOSES
