Открытый узел

CAB HEADLINERS, CAB DOME LIGHT AND FENDER COVER

Серийный номер

Бренд

John Deere

Читать описание

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	T133353	1	Headliner	L.H. (SUB T161427), (ALSO ORDER AT173908, T135736, T157811 AND (2) T161294)
2	T133350	1	Headliner	FRONT (USE WITHOUT RADIO) (SUB T157811), (ALSO ORDER AT173908, T135736, AT335410 AND (2) T161294)
2	T140363	1	Headliner	FRONT (USE WITH RADIO) (NOT ILLUSTRATED), (SUB T158351 ) (ALSO ORDER AT173908, AT335410 AND (2) T161294)
2	T158351	1	Headliner	(FRONT) USE WITH RADIO (NOT ILLUSTRATED), (SUB FOR T140363)
3	T82792	2	Nut	-
4	AR48015	1	Bulb	(USE WITH AT151231)(DOME LIGHT EYE BALL)
4	AT334583	1	Adapter	-
4	L41333	1	Bulb	(DOME LIGHT), (SUB FOR AT151255, THIS APPLICATION)
4	AT173908	1	Lamp	-
4	AT334856	1	Light Kit	(INCLUDES AT173908, AT334583, L41333), (SUB FOR AT151231)
5	T134962	4	Retainer	(USE WIHTOUT RADIO)
6	T83060	6	Screw	WITHOUT RADIO
6	T134895	7	Self-Locking Screw	(USE WITH RADIO)
7	T134961	4	Cap	(USE WITHOUT RADIO)
9	T63019	1	Weatherstrip	(SUB FOR T59938)
9	T158840	2	Seal	-
10	24H1646	4	Washer	17/64" X 3/4" X 0.060", (LEFT FENDER COVER TO FENDER AND FLOOR SCREWS 3-LOWER SIDE 1-FLOOR), (SUB FOR 24M7139, THIS APPLICATION)
11	T133674	6	Self-Locking Screw	-
11	T134874	6	Self-Locking Screw	-
13	T133352	1	Headliner	R.H. (SUB T161427), (ALSO ORDER AT173908, T135736, T157811 AND (2) T161294)
14	T141043	1	Headliner	CENTER (SUB T161427), (ALSO ORDER AT173908, T135736, T157811 AND (2) T161294 ) (SUB FOR T133351)
15	24M7100	2	Washer	6.600 X 22 X 2 mm, (FENDER COVER TO FENDER AND FLOOR SCREWS TOP HOLES UNDER LOUVERS)
16	T141235	1	Holder	SWING LOCK PIN
16	T141234	1	Holder	-
17	14M7165	2	Lock Nut	M6
18	24H1287	4	Washer	9/32" X 5/8" X 0.065"
19	19M7874	2	Cap Screw	M6 X 30
20	AT140978	4	Louver	-
21	AT177227	2	Louver	-
22	AT227669	4	Louver	(SUB FOR AT151036)
23	T159945	20	Screw	-
24	T159946	20	Nut	-
25	28H1611	4	Washer	0.269" X 0.405" X 5/16", (HEADLINER)
25	28H1611	2	Washer	0.269" X 0.405" X 5/16", (HEADLINER)
26	AT335410	1	Headliner	(REAR), (SUB FOR T155431 AND T161427 ) (ALSO ORDER (2) T161294)
27	T157811	1	Headliner	(FRONT) (WITHOUT RADIO)
28	AT173908	1	Lamp	(INCLUDES SWITCH AND BULB)
28	L41333	1	Bulb	(DOME LIGHT)
29	T161294	1	Plug	REAR HEADLINER
8A	T82791	2	Screw	-
8B	T83060	2	Screw	-
12A	T141257	1	Cover	(SUB FOR T133354)L.H.
12B	AT177064	1	Cover	-
12B	AT174337	1	Cover	-

CAB HEADLINERS, CAB DOME LIGHT AND FENDER COVER

Нет текстового описания
