BREAKAWAY COUPLER AND OPERATING LEVER [02D12]

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	R34399	2	Snap Ring	-
2	R32356	2	SNAP RING	-
3	R69281	12	Ball	6MM (1/4")
4	R26484	4	Back-Up Ring	-
5	R65286	4	O-RING	(SUB FOR A3917R, THIS APPLICATION)
6	R34397	2	SOCKET OUTLET	-
7	R375R	2	O-Ring	-
8	R26482	2	Ring	-
9	R28084	2	SPRING	-
10	R34400	2	PLUG	-
11	R26483	2	SNAP RING	-
12	R34398	2	SLEEVE	-
13	30H15	2	PLUG	1-1/8"
14	R72653	2	Snap Ring	(SUB FOR M2396T)
15	R31890	2	Spring	-
16	R26480	4	BACK-UP RING	-
17	A4730R	4	O-Ring	-
18	R72654	1	Snap Ring	(SUB FOR R27507)
19	24H1286	1	Washer	9/32" X 1/2" X 1/16"
20	R49191	1	STUD	-
21	12H303	1	Lock Washer	5/16"
22	AR52621	1	COUPLING	R.H. (SINGLE) (MARKED R39109)
22	AR52622	1	COUPLING	L.H. (DUAL) (SUB R39110, R49191, R72654, 12H7065 AND 24H1286)
24	AR99100	2	LEVER	(SUB FOR AR33877 OR AR82576)
25	D2361R	2	Ball	13MM (1/2")
26	R495R	2	O-Ring	(SUB R59343, THIS APPLICATION)
27	R26485	2	BACK-UP RING	-
28	R39110	1	HOUSING	(DUAL)
29	AR39036	1	BREAKAWAY COUPLER	R.H. (SINGLE)
29	AR39037	1	BREAKAWAY COUPLER	L.H. (DUAL)
30	N10065	1	Bushing	-
31	R32419	1	COVER	(SUB R80324)
32	AT32332	2	Elbow Fitting	(SUB FOR AR26763)
33	R26375	2	O-Ring	-
34	19H1831	1	Cap Screw	1/2" X 2", (SINGLE)
34	19H1974	1	Cap Screw	1/2" X 2-3/4", (DUAL)
23A	R51285	1	PLATE	(SUB FOR R34402 AND AR75958) (SUB R61957)
23B	AR75958	1	CAM	(SUB FOR R51285) (SUB R61957)
