73 Selective Control Valves-Poppet And Spool Type

Серийный номер

Бренд

John Deere

Читать описание

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
-	-	1	REMOTE CYLINDER AND HOSES	-
-	-	1	SELECTIVE CONTROL VALVE (SPOOL TYPE) WITH 2 SELECT. CONTROL VALVES (POPPET TYPE / SGB)	-
-	-	1	SELECTIVE CONTROL VALVE (SPOOL TYPE / SGB)	-
-	-	1	SELECTIVE CONTROL VALVE (POPPET TYPE)	-
-	-	1	SELECTIVE CONTROL VALVE (POPPET TYPE)	-
-	-	1	REMOTE CYLINDER SEAL RING SET	-
-	-	1	REMOTE CYLINDER PARTS (3" X 8" / MECHANICAL STOP)	-
-	-	1	REMOTE CYLINDER PARTS (3" X 8" / HYDRAULIC STOP)	-
-	-	1	REMOTE CYLINDER PARTS (2-1/2" X 8")	-
-	-	1	REMOTE CYLINDER AND HOSES (3" X 8")	-
-	-	1	SELECTIVE CONTROL VALVE (SPOOL TYPE) WITH 2 SELECT. CONTROL VALVES (POPPET TYPE)	-
-	-	1	REMOTE CONTROL CYLINDER, INDIVIDUAL PARTS	-
-	-	1	REMOTE CONTROL CYLINDER OVERHAUL KIT (3" X 8" AND HYDRAULIC STOP)	-
-	-	1	REMOTE CONTROL CYLINDER CONVERSION KIT (3" X 8", HYDRAULIC STOP TO MECHANICAL STOP)	-
-	-	1	RECEPTACLE FOR BREAKEAWAY COUPLER	-
-	-	1	QUICK COUPLER (WITH GRESEN SELECTIVE CONTROL VALVES / GP - TRACTORS)	-
-	-	1	QUICK COUPLER (WITH GRESEN SELECTIVE CONTROL VALVES / GP - TRACTORS WITH SGB)	-
-	-	1	Quick Coupler (Spool Type) With Foldable Two-Post Roll-Gard™	-
-	-	1	QUICK COUPLER (SPOOL TYPE)	-
-	-	1	SELECTIVE CONTROL VALVE LEVERS (SPOOL TYPE)	-
-	-	1	TRANSMISSION AND HYDRAULIC OIL	-
-	-	1	SELECTIVE CONTROL VALVE STOP (SGB)	-
-	-	1	Selective Control Valve Overhaul Kit	-
-	-	1	SELECTIVE CONTROL VALVE LINKAGE (SPOOL TYPE / SGB)	-
-	-	1	SELECTIVE CONTROL VALVE LINKAGE (POPPET TYPE)	-
-	-	1	SELECTIVE CONTROL VALVE LINKAGE (POPPET TYPE / LOW VERSION)	-
-	-	1	SELECTIVE CONTROL VALVE LINKAGE (POPPET AND SPOOL TYPE / SGB)	-
-	-	1	SELECTIVE CONTROL VALVE LEVERS (SPOOL TYPE) (LOW PROFILE)	-
-	-	1	QUICK COUPLER (SPOOL TYPE)	-
-	-	1	SELECTIVE CONTROL VALVE LEVERS (SPOOL TYPE)	-
-	-	1	SELECTIVE CONTROL VALVE GRESEN / LINKAGE FOR GP - TRACTORS WITH SGB	-
-	-	1	SELECTIVE CONTROL VALVE GRESEN / LINKAGE FOR GP - TRACTORS	-
-	-	1	SELECTIVE CONTROL VALVE BLOCK (SPOOL TYPE WITH SGB)	-
-	-	1	SELECTIVE CONTROL VALVE ASSY. (POPPET TYPE)	-
-	-	1	SELECTIVE CONTROL VALVE (SPOOL TYPE), (INDIVIDUAL PARTS)	-
-	-	1	SELECTIVE CONTROL VALVE (SPOOL TYPE), (INDIVIDUAL PARTS)	-
-	-	1	SELECTIVE CONTROL VALVE (SPOOL TYPE), (INDIVIDUAL PARTS)	-
-	-	1	O-RING KIT	-
-	-	1	OIL LINES FOR QUICK-DISCONNECT COUPLERS (WITH GRESEN SELECTIVE CONTROL VALVES / GP - TRACTORS)	-
-	-	1	OIL LINES FOR QUICK-DISCONNECT COUPLERS (SPOOL TYPE)	-
-	-	1	OIL LINES FOR QUICK-DISCONNECT COUPLERS (SPOOL TYPE / SGB)	-
-	-	1	OIL LINES FOR QUICK-DISCONNECT COUPLERS (POPPET TYPE)	-
-	-	1	OIL LINES FOR QUICK-DISCON. COUPLERS (WITH GRESEN SELECT. CONTROL VALVES / GP - TRACTORS WITH SGB)	-
-	-	1	OIL LINES FOR QUICK COUPLERS (SGB)	-
-	-	1	OIL LINES FOR ISO BREAKAWAY COUPLERS (SGB)	-
-	-	1	OIL LINES FOR ISO BREAKAWAY COUPLERS (POPPET TYPE)	-
-	-	1	OIL LINES FOR GRESEN SELECTIVE CONTROL VALVES (GP - TRACTORS)	-
-	-	1	OIL LINES FOR REAR QUICK-DISCONNECT COUPLERS (SPOOL TYPE)	-
-	-	1	LEAK-OFF OIL LINE (REAR) FOR ISO BREAKAWAY COUPLERS (POPPET TYPE)	-
-	-	1	LEAK-OFF OIL LINE (FRONT) FOR ISO BREAKAWAY COUPLERS (POPPET TYPE)	-
-	-	1	IMPLEMENT HYDRAULIC OIL LINES AND FITTINGS	-
-	-	1	DUST CAP FOR ISO BREAKAWAY COUPLERS (POPPET TYPE)	-
-	-	1	BULK FLEXIBLE OIL LINE AND REUSABLE LOK-PIN COUPLINGS	-
-	-	1	BREAKEAWAY COUPLER (POPPET TYPE)	-
-	-	1	BRACKET FOR SELECTIVE CONTROL VALVES (SPOOL TYPE WITH SGB)	-
-	-	1	BRACKET FOR SELECTIVE CONTROL VALVES (POPPET TYPE WITH SGB)	-
-	-	1	OIL LINES/RETURN FILTER FOR SELECTIVE CONTROL VALVES (POPPET TYPE / SGB)	-
-	-	1	QUICK COUPLER (SPOOL TYPE)	-
-	-	1	QUICK COUPLER (SPOOL TYPE / SGB)	-
-	-	1	QUICK COUPLER (SPOOL AND POPPET TYPE / SGB)	-
-	-	1	QUICK COUPLER (POPPET TYPE)	-
-	-	1	OIL LINES/RETURN FILTER FOR SELECTIVE CONTROL VALVES (SPOOL TYPE)	-
-	-	1	OIL LINES/RETURN FILTER FOR SELECTIVE CONTROL VALVES (SPOOL TYPE)	-
-	-	1	OIL LINES/RETURN FILTER FOR SELECTIVE CONTROL VALVES (SPOOL TYPE WITH SGB)	-
-	-	1	OIL LINES/RETURN FILTER FOR SELECTIVE CONTROL VALVES (POPPET TYPE)	-
-	-	1	BRACKET FOR SELECTIVE CONTROL VALVES (POPPET TYPE WITH SGB)	-
-	-	1	OIL LINES/RETURN FILTER FOR GRESEN SELECTIVE CONTROL VALVES (FOR GP - TRACTORS)	-
-	-	1	OIL LINES/RETURN FILTER FOR GRESEN SELECTIVE CONTROL VALVES (FOR GP - TRACTORS WITH SGB)	-
-	-	1	OIL LINES-SELECTIVE CONTROL VALVES (SPOOL TYPE)	-
-	-	1	OIL LINES-SELECTIVE CONTROL VALVES (SPOOL TYPE)	-
-	-	1	OIL LINES FOR SELECTIVE CONTROL VALVE (SPOOL TYPE) WITH TWO SELECTIVE CONTROL VALVE (POPPET TYPE)	-
-	-	1	OIL LINES FOR SELECTIVE CONTROL VALVE (POPPET TYPE)	-
-	-	1	OIL LINES FOR SELECTIVE CONTROL VALVE (POPPET TYPE / SGB)	-
-	-	1	OIL LINES FOR SELEC. CONTROL VALVE (SPOOL TYPE) WITH TWO SELEC. CONTROL VALVE (POPPET TYPE / SGB)	-

73 Selective Control Valves-Poppet And Spool Type

Нет текстового описания
