DIFFERENTIAL LOCK VALVE OIL PIPES (POWER SHIFT) [02D15]

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	R30903	1	O-Ring	-
2	R39597	1	ADAPTER FITTING	-
3	AR42613	1	OIL LINE	INNER, (SUB FOR AR33967)
4	T16911	1	SHIM	-
5	AR34569	1	FITTING	-
6	AR34568	1	OIL LINE	OUTER, (ROW-CROP)
6	AR39823	1	LINE	OUTER (HI-CROP) (NLA)
7	AR35710	1	ELBOW FITTING	90°
8	R26286	1	O-Ring	-
9	R27272	1	Fitting	-
10	R26286	1	O-Ring	-
11	R26286	1	O-Ring	-
12	AT32333	1	ELBOW FITTING	90°, (SUB FOR AR26771)
12	AR40475	1	ELBOW FITTING	90°
13	R26286	1	O-Ring	-
14	AT32333	1	ELBOW FITTING	90°, (SUB FOR AR26771)
15	AR34733	1	OIL LINE	-
16	AR34732	1	LINE	(SUB AR40603, AR40472, AR40475, AR40478, R31654 AND R31655)
16	AR40478	1	OIL LINE	-
17	A147R	1	WASHER	-
18	R42357	1	CLAMP	(SUB FOR R27545)
18	R31654	1	CLAMP	-
19	R26287	1	O-Ring	-
20	AR39679	1	TEE FITTING	(SUB AR40603, AR40472, AR40475, AR40478, R31654 AND R31655)
20	AR40472	1	TEE FITTING	-
21	19H2661	1	Cap Screw	5/16" X 1-3/8"
22	12H303	1	Lock Washer	5/16"
23	R31654	1	CLAMP	-
24	R31655	1	STRAP	-
25	28H3381	1	Spacer	3/8" X 5/8"
26	AR39678	1	OIL LINE	LOWER
27	AR40603	1	LINE	BRACLE VALVE TO DIFFERENTIAL LOCK VALVE, (SUB AR40472, AR40475, AR40478, R31654 AND R31655)

DIFFERENTIAL LOCK VALVE OIL PIPES (POWER SHIFT) [02D15]
