GENERATOR ASSEMBLY (REPLACEMENT) (DELCO-REMY NO. 1947579) [01H07]

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	AR11100	1	HOLDER	(SET) (NLA)
2	AR40217	1	HOLDER	(SET)
3	T11651	2	SHIM	(NLA)
4	T11649	2	ARM	-
5	T11652	2	SPRING	-
6	21H1309	2	Screw	0.138" X 1/4"
7	12H314	2	Lock Washer	0.138"
8	AR11074	2	BRUSH	-
9	-	1	Part 9	(ORDER TY1440)
10	21H1280	2	SCREW	3/8" X 3/4", (SUB FOR T18353)
11	21H1127	1	SCREW	0.190" X 7/16"
12	R11087	1	DOWEL PIN	-
13	R11109	1	Plate	(NLA)
14	R11110	1	GASKET	-
15	R11205	1	OIL SLINGER	(NLA)
16	JD9449	1	Ball Bearing	(SUB FOR JD9281)
17	R11204	1	PLATE	(NLA)
18	R11089	1	WASHER	-
19	R11203	1	FRAME	(NLA)
20	R11200	1	BRACKET	(NLA)
21	T11648	1	LOCKING COLLAR	-
22	T10745	1	Washer	-
23	R11049	1	Nut	-
24	R11160	2	INSULATOR	-
25	R11161	2	SHOE	(NLA)
26	AR11101	1	FIELD WINDING COIL	(NLA)
27	R32018	1	Elec. Connector Terminal	(SUB FOR R11043)
28	AR40436	1	STUD	(SUB FOR 1858749)
29	1858749	1	INSULATOR	(SUB AR40436)
30	R11098	1	WASHER	(NLA)
31	24H1287	2	Washer	9/32" X 5/8" X 0.065"
32	12H316	1	Lock Washer	0.216"
33	14H608	1	NUT	0.216"
34	T11656	1	STUD	-
35	R11113	1	WASHER	-
36	R11088	1	WASHER	-
37	26H72	1	Shaft Key	1/8" X 5/8"
38	AR11118	1	ARMATURE	(NLA)
39	R11165	1	CAP	(NLA)
40	R11164	1	WASHER	(NLA)
41	R11086	1	Dowel Pin	-
42	R11202	1	RETAINER	(NLA)
43	AR11117	1	FRAME	(NLA)
44	R11201	1	WICK	-
45	E2302RT	1	OIL CUP	-
46	12H303	2	Lock Washer	5/16"
47	R11158	2	BOLT	(NLA)
..	AR21906	1	DC GENERATOR	(20 AMP) (SUB TY1440)
..	TY1440	1	DC GENERATOR	(20 AMP) (SUB FOR AR21906)
..	SE501389	1	GENERATOR	(REMAN FOR AR21906)
