BREAKAWAY COUPLER AND BRACKET (TRACTOR SERIAL NO. 042001- ) [02G08]

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	R28006	2	CAP	-
2	R26485	2	BACK-UP RING	-
3	R495R	2	O-Ring	-
4	R34397	2	SOCKET OUTLET	-
5	R26484	4	Back-Up Ring	-
6	A3917R	2	O-Ring	-
7	400R	12	Ball	-
8	R375R	2	O-Ring	-
9	R26482	2	Ring	-
10	D2361R	2	Ball	-
11	R28084	2	SPRING	-
12	R34400	2	PLUG	-
13	R26483	2	SNAP RING	-
14	R34489	1	COUPLING	-
15	R26480	4	BACK-UP RING	(SUB R65285)
16	A4730R	4	O-Ring	-
17	A4847R	2	Washer	-
18	T19200	1	BRACKET	(NLA)
19	R34398	2	SLEEVE	-
20	R34402	1	CAM	(SUB R61957)
21	R32356	2	SNAP RING	-
22	R34399	2	Snap Ring	-
23	R27430	2	HYD. QUICK-CONNECT COUPLER	-
24	D2361R	2	Ball	-
25	R28084	2	SPRING	-
26	R28085	2	GUIDE	(SUB RE15361)
27	R59633	2	WEAR RING	(SUB FOR R28204)
28	AR30210	2	HYDR.QUICK COUPLER PLUG	(SUB AR93819)
29	R30818	1	SPRING	-
30	AR82576	2	LEVER	(SUB FOR AR33877) (SUB AR99100)
31	R31890	2	Spring	-
32	R72653	2	Snap Ring	(SUB FOR M2396T)
33	34H244	2	SPRING PIN	1/8" X 9/16"
34	19H1900	2	Cap Screw	5/16" X 3/4"
35	12H303	2	Lock Washer	5/16"
36	M1370T	2	ADAPTER FITTING	-
37	12H304	3	Lock Washer	3/8"
38	19H2128	3	CAP SCREW	3/8" X 3"
39	12H301	2	Lock Washer	1/2"
40	19H2473	2	Cap Screw	1/2" X 1-3/4"
41	R49193	2	Link Chain	(SUB FOR A3184R) (SUB AN163885)
42	37H97	4	SCREW	0.242" X 3/4", (SUB FOR A4322R)
43	R34589	2	WASHER	-
44	AR52623	2	PLUG	(SUB FOR AR34059)

BREAKAWAY COUPLER AND BRACKET (TRACTOR SERIAL NO. 042001- ) [02G08]
