Открытый узел

22 ENGINE (45001 - )

22 ENGINE (45001 - )

22 ENGINE (45001 - )

22 ENGINE (45001 - )

22 ENGINE (45001 - )

22 ENGINE (45001 - )

Серийный номер

Бренд

John Deere

Читать описание

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

22 ENGINE (45001 - )

Нет текстового описания

№ на схеме	Серийный номер	Кол-во	Название	Описание
-	-	1	OIL COOLER	-
-	-	1	SENSOR, OIL PRESSURE	-
-	-	1	Rocker Arm / Shaft / Tappet / Push Rod	-
-	-	1	PUMP INJECTION, SOLENOID	-
-	-	1	PISTON / LINER, KIT	-
-	-	1	OIL PUMP	-
-	-	1	OIL PAN	-
-	-	1	OIL FILTER / ADAPTER	-
-	-	1	OIL FILLER NECK AND OIL DIPSTICK - RH SIDE	-
-	-	1	SET OF FUEL INJECTION LINES	-
-	-	1	LIQUID GASKET	-
-	-	1	INTERMEDIATE HOUSING (OIL COOLER / WATER PUMP) - KIT	-
-	-	1	INTAKE MANIFOLD	-
-	-	1	INTAKE MANIFOLD	-
-	-	1	INJECTION NOZZLE	-
-	-	1	IDLE GEAR (LOWER)	-
-	-	1	GREASE FOR CAMSHAFT BUSHING	-
-	-	1	GASKET KIT, TUNE-UP	-
-	-	1	STARTING MOTOR	-
-	-	1	STARTING MOTOR - ENGINE 6.8L	-
-	-	1	THERMOSTAT (SIMPLE)	-
-	-	1	THERMOSTAT / COVER	-
-	-	1	THERMOSTAT / COVER	-
-	-	1	TIMING GEAR COVER - ENGINE 6.8L	-
-	-	1	TURBOCHARGER	-
-	-	1	TURBOCHARGER OIL LINES	-
-	-	1	UPPER IDLE GEAR	-
-	-	1	VALVE / VALVE SEAT / SPRING / ROTATOR	-
-	-	1	VALVE COVERS	-
-	-	1	WATER PUMP (HIGH CAPACITY)	-
-	-	1	WATER PUMP INTAKE	-
-	-	1	WATER PUMP PULLEY	-
-	-	1	WATER TEMPERATURE SENSOR	-
-	-	1	BELT TENSIONER	-
-	-	1	CYLINDER BLOCK WITH MOVABLE PARTS	-
-	-	1	CYLINDER BLOCK	-
-	-	1	CRANKSHAFT PULLEY AND TORSIONAL DAMPENER	-
-	-	1	COVER WITHOUT OIL FILLER NECK AND PLUG WITHOUT OIL DIPSTICK (RH SIDE)	-
-	-	1	COOLANT	-
-	-	1	CONNECTING RODS / BEARINGS	-
-	-	1	CAMSHAFTS	-
-	-	1	BREATHER	-
-	-	1	CYLINDER BLOCK WITH MOVABLE PARTS - ENGINE 6.8L	-
-	-	1	BELT	-
-	-	1	ALTERNATOR PARTS	-
-	-	1	ALTERNATOR BRACKET	-
-	-	1	ALTERNATOR	-
-	-	1	AIR COMPRESSOR	-
-	-	1	ADAPTER EXHAUST SYSTEM	-
-	-	1	ADAPTER EXHAUST	-
-	-	1	ADAPTER / PIPES OIL	-
-	-	1	CYLINDER HEAD	-
-	-	1	ENGINE GASKET SET, OVERHAUL	-
-	-	1	ENGINE GASKET SET, OVERHAUL	-
-	-	1	ENGINE LIFT STRAPS	-
-	-	1	ENGINE SPEED SENSOR	-
-	-	1	EXHAUST MANIFOLD	-
-	-	1	FAN	-
-	-	1	FAN BRACKET	-
-	-	1	FLYWHEEL	-
-	-	1	FLYWHEEL HOUSING	-
-	-	1	FRONT PLATE	-
-	-	1	FUEL FILTER / BRACKET	-
-	-	1	FUEL FILTER/SEDIMENT BOWL	-
-	-	1	FUEL INJECTION PUMP	-
-	-	1	FUEL PUMP WITH HOSE FITTING	-
