POWER STEERING LINES (HYDROSTATIC TRANSMISSION)

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
1	19M7866	4	Screw	M8 X 20, (HS, HEAD MARKED 10.9)
2	LVA10242	1	Oil Cooler	-
3	T77857	3	O-Ring	12.421 X 1.778 mm (0.489" X 0.070")
4	LVA10279	1	Line	(PS VALVE TO COOLER)
5	LVA11284	1	Line	(COOLER TO HYDROSTATIC TRANSMISSION CHARGE FILTER)
6	LVA10289	1	Line	(STEERING PUMP TO PS VALVE)
7	38H5181	1	Adapter Fitting	-
8	LVA10420	1	Hydraulic Filter	-
8	LVA10419	1	Hydraulic Filter	SPIN-ON
9	19M7785	3	Screw	M10 X 25, (HS, HEAD MARKED 10.9)
10	14M7397	1	Lock Nut	M6
11	M135958	1	Clamp	-
12	M135960	1	Strap	-
13	AM126806	1	Clamp	-
14	51M7043	1	O-Ring	15.300 X 2.200 mm
15	LVA10280	1	Line	(PS VALVE TO FRONT AXLE)
16	LVA10281	1	Line	(PS VALVE TO FRONT AXLE)
17	T77613	2	O-Ring	-
18	38H5003	1	Adapter Fitting	-
19	LVA11706	1	Hose	(RH STEERING CYLINDER ROD END)
20	LVA11707	1	Hose	(LH STEERING CYLINDER HEAD END)
21	T24802	3	Clip	-
22	38H5001	1	Adapter Fitting	(A)
23	T77814	1	O-Ring	(A)
24	51M7040	1	O-Ring	9.300 X 2.200 mm, (A)
25	-	1	Part 26	HYDROSTATIC TRANSMISSION CHARGE PORT
26	38H5076	1	Adapter Fitting	-
26	38H5003	1	Adapter Fitting	-
27	51M7043	1	O-Ring	15.300 X 2.200 mm
27	51M7045	1	O-Ring	19.300 X 2.200 mm
28	T77857	1	O-Ring	12.421 X 1.778 mm (0.489" X 0.070")
29	61M5076	1	Adapter Fitting	-
29	61M5003	1	Adapter Fitting	-
30	T77857	1	O-Ring	12.421 X 1.778 mm (0.489" X 0.070")
31	51M7047	1	O-Ring	23.600 X 2.900 mm
32	61M5181	2	Adapter Fitting	-
33	61M5001	1	Adapter Fitting	(SUB COMPONENTS) (PARTS MARKED (A))
34	61M5003	1	Adapter Fitting	-

POWER STEERING LINES (HYDROSTATIC TRANSMISSION)
