DIRECTIONAL CONTROL VALVE COMPONENTS [01J19]

Серийный номер

Бренд

John Deere

100

баллов

Нашли неточность, знаете аналог или есть вопрос?

Воспользуйтесь этой формой и получите бонусы

№ на схеме	Серийный номер	Кол-во	Название	Описание
0	F058438	1	VALVE	-
1	F039218	1	RELIEF VALVE	230 BAR
2	F053968	2	PLUG	-
3	F053975	1	PLUG	-
4	F030940	1	Check Valve	-
5	F030971	8	Seal Kit	-
6	F030933	1	Strainer	-
7	F030937	1	Hydraulic Pressure Valve	R, SIZE GREEN
7	F053971	1	Hydraulic Pressure Valve	R, SIZE RED
8	F053969	1	Plug	-
9	F053970	1	PLUG	-
10	F034250	1	Clamp Kit	-
11	F053967	1	Rod Kit	-
12	F030964	11	Pressure Relief Fitting	230 BAR
13	F030958	2	Check Valve	-
14	F030959	1	PLUG	-
15	F030952	7	Valve Stack	-
16	F034252	7	Spring	-
17	F034249	7	Cap Kit	-
18	F433693	7	SEAL KIT	-
19	F030955	1	Seal Kit	-
19	F053974	1	COMPENSATOR	KH, SIZE RED
19	F053973	1	Compensator	KH, SIZE GREEN
19	F433696	1	Compensator	KH, SIZE BLUE
19	F050841	1	Compensator	K, SIZE GREEN
19	F050840	1	Compensator	K, SIZE BLUE
19	F050842	1	COMPENSATOR	K, SIZE RED
20	F050843	5	CHECK VALVE	N, SIZE BLUE
20	F050844	5	CHECK VALVE	N, SIZE GREEN
20	F050845	5	CHECK VALVE	N, SIZE RED
20	F030955	1	Seal Kit	-
21	F030974	14	BRACKET KIT	-
22	F061736	14	Elec.Proportional Valve	-
23	F030943	1	SEAL KIT	-
24	F031705	2	Orifice	1.0MM, SEE PAGE 3762/5
24	F031703	2	Orifice	0.6MM, SEE PAGE 3762/5
24	F031704	3	Orifice	0.8MM, SEE PAGE 3762/5
24	F031706	7	Orifice	1.2MM, SEE PAGE 3762/5
25	F433695	7	SEAL KIT	-
26	F030951	1	Cover	FOR F056635 AND F058439
27	F013575	2	Orifice	0.8MM FOR VALVE F056635
27	F433705	2	Orifice	1.0MM FOR VALVE F058439
28	F004568	14	O-RING	-
29	F030954	2	Pressure Relief Valve	-
30	F433698	1	Seal Kit	-
31	F001624	28	SCREW	-
32	F004565	1	O-RING	-

DIRECTIONAL CONTROL VALVE COMPONENTS [01J19]
